Flutter 通过Clipper实现各种自定义形状的示例代码

Flutter 通过Clipper实现各种自定义形状的示例代码

本文介绍了Flutter 通过Clipper实现各种自定http://义形状的示例代码,分享给大家,具体如下:

ClipOval 圆形裁剪

ClipOval(

child: SizedBox(

width: 120.0,

height: 120.0,

child: Image.asset(

Config.assets_avatar_1,

),

),

);

CircleAvatar 圆形头像

CircleAvatar(

radius: 60.0,

backgroundImage: AssetImage(

Config.assets_avatar_1,

),

);

Container Decoration 装饰形状

通过BoxShape.circle实现圆形图片

Container(

width: 120.0,

height: 120.0,

decoration: BoxDecoration(

shape: BoxShape.circle,

image: DecorationImage(

image: AssetImage(

Config.assets_avatar_1,

),

),

)

);

通过BorderRadius实现圆形图片

Container(

width: 120.0,

height: 120.0,

decoration: BoxDecoration(

borderRadius: BorderRadius.all(Radius.circular(60.0)),

image: DecorationImage(

image: AssetImage(

Config.assets_avatar_1,

),

),

),

)

ClipPath 路径剪裁

ClipPath(

clipper: TriangleClipper(ClipperPosition.LeftTop),

child: Container(

width: 16.0,

height: 16.0,

decoration: BoxDecoration(

color: Colors.blue,

),

),

);

enum ClipperPosition {

LeftTop,

RightTop,

}

class TriangleClipper extends CustomClipper {

final ClipperPosition position;

TriangleClipper(this.position);

@override

Path getClip(Size size) {

final path = Path();

path.lineTo(0.0, 0.0);

if (position == ClipperPosition.LeftTop) {

path.lineTo(size.width, 0.0);

path.lineTo(size.width, size.height);

} else if (position == ClipperPosition.RightTop) {

path.lineTo(size.width, 0.0);

path.lineTo(0.0, size.height);

}

path.close();

return path;

}

@override

bool shouldReclip(CustomClipper oldClipper) {

return false;

}

}

ClipRect 矩形剪裁

Container(

alignment: Alignment-Center,

color: Colors.transparent,

child: Container(

color: Colors.green,

child: ClipRect(

clipper: _RectClipper(20.0),

child: Image.asset(

Config.assets_avatar_1,

width: 160.0,

height: 160.0,

fit: BoxFit.fill,

),

),

),

);

class _RectClipper extends CustomClipper {

/// Remove side of size

final double removeSize;

_RectClipper(this.removeSize);

@override

Rect getClip(Size size) {

return new Rect.fromLTRB(

removeSize,

removeSize,

size.width - removeSize,

size.height - removeSize,

);

}

@override

bool shouldReclip(CustomClipper oldClipper) {

return false;

}

}

ClipRRect 圆角矩形剪裁

ClipRRect(

borderRadius: BorderRadius.all(Radius.circular(16.0)),

child: Image.asset(

ConfiGqMiGYSmPg.assets_avatar_1,

fit: BoxFit.fill,

width: 120.0,

height: 120.0,

),

);

Star Rating(CustomPaint) 评分控件

评分控件 UI图

实现方案

使用CustomPaint结合ClipPath画出单个五角星;

使用Stack渲染两层画面

背景层,一排灰色五角星  前景层,一排亮色五角星,并使用ClipRect截取一定Width

实现代码

class StarRatingDemo extends StatefulWidget {

@override

_StarRatingDemoState createState() => _StarRatingDemoState();

}

class _StarRatingDemoState extends State {

/// ClipPath Star Rating

_buildClipPathStarRating(double rate, int count) {

return Container(

padding: EdgeInsets.fromLTRB(24.0, 16.0, 24.0, 0.0),

chGqMiGYSmPild: StaticRatingBar(

size: 50.0,

rate: rate,

count: count,

),

);

}

@override

Widget build(BuildContext context) {

return Scaffold(

appBar: AppBar(

centerTitle: true,

title: Text('Star Rating'),

),

body: ListView(

physics: BouncingScrollPhysics(),

children: [

// _buildClipPathStarRating(1.0, 1),

_buildClipPathStarRating(0.5, 5),

_buildClipPathStarRating(2.0, 5),

_buildClipPathStarRating(3.0, 5),

_buildClipPathStarRating(4.0, 5),

_buildClipPathStarRating(5.0, 5),

_buildClipPathStarRating(5.5, 6),

SizedBox(height: 16.0),

],

),

);

}

}

class StaticRatingBar extends StatelessWidget {

/// Number of stars

final int count;

/// Init rate

final double rate;

/// Size of the starts

final double size;

final Color colorLight;

final Color colorDark;

StaticRatingBar({

this.rate = 5,

this.colorLight = const Color(0xFF1E88E5),

this.colorDark = const Color(0xFFEEEEEE),

this.count = 5,

this.size = 60,

});

Widget buildDarkStar() {

return SizedBox(

width: size * count,

height: size,

child: CustomPaint(

painter: _PainterStars(

count: count,

color: colorDark,

strokeWidth: 0.0,

size: this.size / 2,

style: PaintingStyle.fill,

),

),

);

}

Widget buildLightStar() {

return ClipRect(

clipper: _RatingBarClipper(rate * size),

child: SizedBox(

height: size,

width: size * count,

child: CustomPaint(

painter: _PainterStars(

count: count,

strokeWidth: 0.0,

color: colorLight,

size: this.size / 2,

style: PaintingStyle.fill,

),

),

),

);

}

@override

Widget build(BuildContext context) {

return Stack(

children: [

buildDarkStar(),

buildLightStar(),

],

);

}

}

class _RatingBarClipper extends CustomClipper {

final double width;

_RatingBarClipper(this.width);

@override

Rect getClip(Size size) {

return Rect.fromLTRB(0.0, 0.0, width, size.height);

}

@override

bool shouldReclip(_RatingBarClipper oldClipper) {

return false;

}

}

class _PainterStars extends CustomPainter {

final double size;

final int count;

final Color color;

final PaintingStyle style;

final double strokeWidth;

_PainterStars({

this.size,

this.count,

this.color,

this.strokeWidth,

this.style,

});

double degree2Radian(int degree) {

return (pi * degree / 180);

}

Path createStarPath(double radius, Path path) {

double radian = degree2Radian(36);

double radiusIn = (radius * sin(radian / 2) / cos(radian)) * 1.1;

path.moveTo((radius * cos(radian / 2)), 0.0);

path.lineTo(

(radius * cos(radian / 2) + radiusIn * sin(radian)),

(radius - radius * sin(radian / 2)),

);

path.lineTo(

(radius * cos(radian / 2) * 2),

(radius - radius * sin(radian / 2)),

);

path.lineTo(

(radius * cos(radian / 2) + radiusIn * cos(radian / 2)),

(radius + radiusIn * sin(radian / 2)),

);

path.lineTo(

(radius * cos(radian / 2) + radius * sin(radian)),

(radius + radius * cos(radian)),

);

path.lineTo((radius * cos(radian / 2)), (radius + radiusIn));

path.lineTo(

(radius * cos(radian / 2) - radius * sin(radian)),

(radius + radius * cos(radian)),

);

path.lineTo(

(radius * cos(radian / 2) - radiusIn * cos(radian / 2)),

(radius + radiusIn * sin(radian / 2)),

);

path.lineTo(0.0, (radius - radius * sin(radian / 2)));

path.lineTo(

(radius * cos(radian / 2) - radiusIn * sin(radian)),

(radius - radius * sin(radian / 2)),

);

path.lineTo((radius * cos(radian / 2)), 0.0);

return path;

}

@override

void paint(Canvas canvas, Size size) {

Paint paint = Paint();

paint.strokeWidth = strokeWidth;

paint.color = color;

paint.style = style;

Path path = Path();

double offset = strokeWidth > 0 ? strokeWidth + 2 : 0.0;

path = createStarPath(this.size - offset, path);

for (int i = 0; i < count - 1; i++) {

path = path.shift(Offset(this.size * 2, 0.0));

path = createStarPath(this.size - offset, path);

}

if (offset > 0) {

path = path.shift(Offset(offset, offset));

}

path.close();

canvas.drawPath(path, paint);

}

@override

bool shouldRepaint(_PainterStars oldDelegate) {

return oldDelegate.size != this.size;

}

}

代码地址

https://github.com/smiling1990/FlutterClipper
