Spring security基于数据库中账户密码认证

Spring security基于数据库中账户密码认证

一、原理分析

前台的登录请求发送到后端后会由spring security进行拦截,即controller层由框架自己提供。这样用户名和密码的认证就需要在service层完成,所以框架需要在service层获取到我们自己的数据库账号信息。

spring security 提供了一个接口 UserDetailsService 来让用户提供账号和密码,其内容如下

public interface UserDetailsService {

UserDetails loadUserByUsername(String username) throws UsernameNotFoundException;

}

用户实现这个接口中的loadUserByUsername方法,通过数据库中查询的账号和密码构造一个UserDetails对象返回给spring security,然后框架自己完成认证操作。

其中UserDetails也是一个接口,spring security用它来封装当前进行认证的用户信息

public interface UserDetails extends Serializable {

Collection extends GrantedAuthority> getAuthorities();

String getPassword();

String getUsername();

boolean isAccountNonExpired();

boolean isAccountNonLocked();

boolean isCredentialsNonExpired();

boolean isEnabled();

}

spring security 自己提供了一个实现类我们可以直接使用,以下是User中的部分代码

public class User implements UserDetails, CredentialsContainer {

private String password;

private final String username;

private final Setauthorities;

private final boolean accountNonExpired; //帐户是否过期

private final boolean accountNonLocked; //帐户是否锁定

private final boolean credentialsNonExpired; //认证是否过期

private final boolean enabled; //帐户是否可用

所以,使用数据库完成认证的关键就是实现UserDetailsService接口,并在loadUserByUsername方法中封装一个框架需要的UserDetails对象,即User对象返回给框架,由框架完成后续的认证操作。

同时需要在spring security的配置文件中指定要用来认证的userService 的bean

二、代码实现

1.新建一个javaWeb工程

新建一个javaweb工程,导入相关依赖,pom文件的内容如下

pom文件

xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">

4.0.0

com.lyy

spring_security_1

1.0-SNAPSHOT

war

spring_security_1 Maven Webapp

http://example.com

UTF-8

5.0.2.RELEASE

1.6.6

1.2.12

5.1.6

3.4.5

5.0.1.RELEASE


org.aspectj

aspectjweaver

1.6.8


org.springframework

spring-aop

${spring.version}


org.springframework

spring-context

${spring.version}


org.springframework

spring-context-support

${spring.version}


org.springframework

spring-web

${spring.version}


org.springframework

spring-orm

${spring.version}


org.springframework

spring-hVAFfUenRDbeans

${spring.version}


org.springframework

spring-core

${spring.version}


org.springframework

spring-test

${spring.version}


org.springframework

spring-webmvc

${spring.version}


org.springframework

spring-tx

${spring.version}


junit

junit

4.12

test


javax.servlet

javax.servlet-api

3.1.0

provided


javax.servlet.jsp

jsp-api

2.0

provided


jstl

jstl

1.2

log4j

log4j

${log4j.version}


org.slf4j

slf4j-api

${slf4j.version}


org.slf4j

slf4j-log4j12

${slf4j.version}

mysql

mysql-connector-java

${mysql.version}


org.mybatis

mybatis

${mybatis.version}


org.mybatis

mybatis-spring

1.3.0


c3p0

c3p0

0.9.1.2

jar

compile


com.github.pagehelper

pagehelper

5.1.2


org.springframework.security

spring-security-web

${spring.security.version}


org.springframework.security

spring-security-config

${spring.security.version}


org.springframework.security

spring-security-core

${spring.security.version}


org.springframework.security

spring-security-taglibs

${spring.security.version}


javax.annotation

jsr250-api

1.0


com.fasterxml.jackson.core

jackson-databind

2.9.7


com.fasterxml.jackson.core

jackson-core

2.9.7


org.projectlombok

lombok

1.16.16



org.apache.tomcat.maven

tomcat7-maven-plugin

2.1

80

/

UTF-8

tomcat7






xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">

4.0.0

com.lyy

spring_security_1

1.0-SNAPSHOT

war

spring_security_1 Maven Webapp

http://example.com

UTF-8

5.0.2.RELEASE

1.6.6

1.2.12

5.1.6

3.4.5

5.0.1.RELEASE


org.aspectj

aspectjweaver

1.6.8


org.springframework

spring-aop

${spring.version}


org.springframework

spring-context

${spring.version}


org.springframework

spring-context-support

${spring.version}


org.springframework

spring-web

${spring.version}


org.springframework

spring-orm

${spring.version}


org.springframework

spring-hVAFfUenRDbeans

${spring.version}


org.springframework

spring-core

${spring.version}


org.springframework

spring-test

${spring.version}


org.springframework

spring-webmvc

${spring.version}


org.springframework

spring-tx

${spring.version}


junit

junit

4.12

test


javax.servlet

javax.servlet-api

3.1.0

provided


javax.servlet.jsp

jsp-api

2.0

provided


jstl

jstl

1.2

log4j

log4j

${log4j.version}


org.slf4j

slf4j-api

${slf4j.version}


org.slf4j

slf4j-log4j12

${slf4j.version}

mysql

mysql-connector-java

${mysql.version}


org.mybatis

mybatis

${mybatis.version}


org.mybatis

mybatis-spring

1.3.0


c3p0

c3p0

0.9.1.2

jar

compile


com.github.pagehelper

pagehelper

5.1.2


org.springframework.security

spring-security-web

${spring.security.version}


org.springframework.security

spring-security-config

${spring.security.version}


org.springframework.security

spring-security-core

${spring.security.version}


org.springframework.security

spring-security-taglibs

${spring.security.version}


javax.annotation

jsr250-api

1.0


com.fasterxml.jackson.core

jackson-databind

2.9.7


com.fasterxml.jackson.core

jackson-core

2.9.7


org.projectlombok

lombok

1.16.16



org.apache.tomcat.maven

tomcat7-maven-plugin

2.1

80

/

UTF-8

tomcat7






在web.xml中配置spring security的过滤器

web.xml

xmlns:xsi="http://w3.org/2001/XMLSchema-instance"

xsi:schemaLocation="http://java.sun.com/xml/ns/javaee

http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd"

version="3.0">

spring security 01

contextConfigLocation

classpath:spring-security.xml,classpath*:applicationContext.xml


org.springframework.web.context.ContextLoaderListener


springSecurityFilterChain

org.springframework.web.filter.DelegatingFilterProxy


springSecurityFilterChain

/*


characterEncodingFilter

org.springframework.web.filter.CharacterEncodingFilter

encodinghVAFfUenRD

UTF-8



characterEncodingFilter

/*


index.html

index.htm

index.jsp

default.html

default.htm

default.jsp



xmlns:xsi="http://w3.org/2001/XMLSchema-instance"

xsi:schemaLocation="http://java.sun.com/xml/ns/javaee

http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd"

version="3.0">

spring security 01

contextConfigLocation

classpath:spring-security.xml,classpath*:applicationContext.xml


org.springframework.web.context.ContextLoaderListener


springSecurityFilterChain

org.springframework.web.filter.DelegatingFilterProxy


springSecurityFilterChain

/*


characterEncodingFilter

org.springframework.web.filter.CharacterEncodingFilter

encodinghVAFfUenRD

UTF-8



characterEncodingFilter

/*


index.html

index.htm

index.jsp

default.html

default.htm

default.jsp



整合spring和mybatis,spring的配置文件applicationContext.xml

spring配置文件

xmlns:xsi="http://w3.org/2001/XMLSchema-instance"

xmlns:context="http://springframework.org/schema/context"

xmlns:aop="http://springframework.org/schema/aop"

xmlns:tx="http://springframework.org/schema/tx"

xsi:schemaLocation="http://springframework.org/schema/beans

http://springframework.org/schema/beans/spring-beans.xsd

http://springframework.org/schema/context

http://springframework.org/schema/context/spring-context.xsd

http://springframework.org/schema/aop

http://springframework.org/schema/aop/spring-aop.xsd

http://springframework.org/schema/tx

http://springframework.org/schema/tx/spring-tx.xsd">








xmlns:xsi="http://w3.org/2001/XMLSchema-instance"

xmlns:context="http://springframework.org/schema/context"

xmlns:aop="http://springframework.org/schema/aop"

xmlns:tx="http://springframework.org/schema/tx"

xsi:schemaLocation="http://springframework.org/schema/beans

http://springframework.org/schema/beans/spring-beans.xsd

http://springframework.org/schema/context

http://springframework.org/schema/context/spring-context.xsd

http://springframework.org/schema/aop

http://springframework.org/schema/aop/spring-aop.xsd

http://springframework.org/schema/tx

http://springframework.org/schema/tx/spring-tx.xsd">








spring security配置文件

spring security的配置文件的内容,spring-security.xml

xmlns:security="http://springframework.org/schema/security"

xmlns:xsi="http://w3.org/2001/XMLSchema-instance"

xsi:schemaLocation="http://springframework.org/schema/beans

http://springframework.org/schema/beans/spring-beans.xsd

http://springframework.org/schema/security

http://springframework.org/schema/security/spring-security.xsd">

username-parameter="username" password-parameter="password"

authentication-failure-forward-url="/failed.html"

default-target-url="/index.html"

/>





xmlns:security="http://springframework.org/schema/security"

xmlns:xsi="http://w3.org/2001/XMLSchema-instance"

xsi:schemaLocation="http://springframework.org/schema/beans

http://springframework.org/schema/beans/spring-beans.xsd

http://springframework.org/schema/security

http://springframework.org/schema/security/spring-security.xsd">

username-parameter="username" password-parameter="password"

authentication-failure-forward-url="/failed.html"

default-target-url="/index.html"

/>





username-parameter="username" password-parameter="password"

authentication-failure-forward-url="/failed.html"

default-target-url="/index.html"

/>





在这个配置文件中要注意的是配置用来认证的userService Bean

创建登录页面和登录失败的页面login.html,failed.html

2.用户认证的实现

新建一个IUserService接口继承UserDetailsService

package com.lyy.service;

import org.springframework.security.core.userdetails.UserDetailsService;

public interface IUserService extends UserDetailsService {

}

实现类如下

@Service("userService")

public class UserServiceImpl implements IUserService {

@Autowired

private IUserDao userDao;

public UserDetails loadUserByUsername(String username) throws UsernameNotFoundException {

UserInfo userInfo = userDao.findByUsername(username);

User user=new User(userInfo.getUsername(),"{noop}"+userInfo.getPassword(),getRoles());

return user;

}

/*给用户赋值角色信息*/

private ListgetRoles(){

Listlist=new ArrayList();

list.add(new SimpleGrantedAuthority("ROLE_USER"));

list.add(new SimpleGrantedAuthority("ROLE_ADMIN"));

return list;

}

}

其中在loadUserByUsername方法中完成查询数据库信息,封装成框架需要的用户信息。

注意 :

UserInfo是封装数据库用户信息的实体类

getRoles用来给用户赋角色信息,spring security认证时用户必须有角色信息,角色信息可以从数据库中查询,在这里直接在代理中写固定值来示意。

用户密码中拼接的"{noop}"字符串是因为我们没有对密码进行加密,所以要告诉框架认证密码时不需要加密。

3.测试

启动工程,访问localhost,会跳转到登录页面,输入数据库中存在的账户和密码就会登录成功并跳转到首页index.html

三、总结

使用数据库完成认证的关键就是实现UserDetailsService接口,并在loadUserByUsername方法中封装一个框架需要的UserDetails对象,即User对象返回给框架,由框架完成后续的认证操作。

同时需要在spring security的配置文件中指定要用来认证的userService 的bean,即实现了loadUserByUsername方法的userService
