Springboot Websocket Stomp 消息订阅推送

Springboot Websocket Stomp 消息订阅推送

目录需求背景websocket协议stomp协议

需求背景

闲话不扯，直奔主题。需要和web前端建立长链接，互相实时通讯，因此想到了websocket，后面随着需求的变更，需要用户订阅主题，实现消息的精准推送，发布订阅等，则想到了STOMP(Simple Text-Orientated Messaging Protocol) 面向消息的简单文本协议。

websocket协议

想到了之前写的一个websocket长链接的demo，也贴上代码供大家参考。

pom文件

直接引入spring-boot-starter-websocket即可。

org.springframework.boot

spring-boot-starter-websocket

声明websocket endpoint

import org.springframework.context.annotation.Bean;

import org.springframework.context.annotation.Configuration;

import org.springframework.web.socket.server.standard.ServerEndpointExporter;

/**

* @ClassName WebSocketConfig

* @Author scott

* @Date 2021/6/16

* @Version V1.0

**/

@Configuration

public class WebSocketConfig {

/**

* 注入一个ServerEndpointExporter,该Bean会自动注册使用@ServerEndpoint注解申明的websocket endpoint

*/

@Bean

public ServerEndpointExporter serverEndpointExporter() {

return new ServerEndpointExporter();

}

}

websocket实现类，其中通过注解监听了各种事件，实现了推送消息等相关逻辑

import com.google.common.cache.Cache;

import com.google.common.cache.CacheBuilder;

import com.ruoyi.common.core.domain.AjaxResult;

import org.slf4j.Logger;

import org.slf4j.LoggerFactory;

import org.springframework.stereotype.Component;

import javax.websocket.*;

import javax.websocket.server.PathParam;

import javax.websocket.server.ServerEndpoint;

import java.util.Objects;

import java.util.Set;

import java.util.concurrent.ConcurrentMap;

import java.util.concurrent.TimeUnit;

import java.util.concurrent.atomic.AtomicInteger;

/**

* @ClassName: DataTypePushWebSocket

* @Author: scott

* @Date: 2021/6/16

**/

@ServerEndpoint(value = "/ws/dataType/push/{token}")

@Component

public class DataTypePushWebSocket {

private static final Logger log = LoggerFactory.getLogger(DataTypePushWebSocket.class);

/**

* 记录当前在线连接数

*/

private static AtomicInteger onlineCount = new AtomicInteger(0);

private static Cache SESSION_CACHE = CacheBuilder.newBuilder()

.initialCapacity(10)

.maximumSize(300)

.expireAfterWrite(10, TimeUnit.MINUTES)

.build();

/**

* 连接建立成功调用的方法

*/

@OnOpen

public void onOpen(Session session, @PathParam("token")String token) {

String sessionId = session.getId();

onlineCount.incrementAndGet(); // 在线数加1

this.sendMessage("sessionId:" + sessionId +",已经和server建立连接", session);

SESSION_CACHE.put(sessionId,session);

log.info("有新连接加入：{}，当前在线连接数为：{}", session.getId(), onlineCount.get());

}

/**

* 连接关闭调用的方法

*/

@OnClose

public void onClose(Session session,@PathParam("token")String token) {

onlineCount.decrementAndGet(); // 在线数减1

SESSION_CACHE.invalidate(session.getId());

log.info("有一连接关闭：{}，当前在线连接数为：{}", session.getId(), onlineCount.get());

}

/**

* 收到客户端消息后调用的方法

*

* @param message 客户端发送过来的消息

http:// */

@OnMessage

public void onMessage(String message, Session session,@PathParam("token")String token) {

log.info("服务端收到客户端[{}]的消息:{}", session.getId(), message);

this.sendMessage("服务端已收到推送消息:" + message, session);

}

@OnError

public void onError(Session session, Throwable error) {

log.error("发生错误");

error.printStackTrace();

}

/**

* 服务端发送消息给客户端

*/

private static void sendMessage(String message, Session toSession) {

try {

log.info("服务端给客户端[{}]发送消息{}", toSession.getId(), message);

toSession.getBasicRemote().sendText(message);

} catch (Exception e) {

log.error("服务端发送消息给客户端失败：{}", e);

}

}

public static AjaxResult sendMessage(String message, String sessionId){

Session session = SESSION_CACHE.getIfPresent(sessionId);

if(Objects.isNull(session)){

return AjaxResult.error("token已失效");

}

sendMessage(message,session);

return AjaxResult.success();

}

public static AjaxResult sendBroadcast(String message){

long size = SESSION_CACHE.size();

if(size <=0){

return AjaxResult.error("当前没有在线客户端，无法推送消息");

}

ConcurrentMap sessionConcurrentMap = SESSION_CACHE.asMap();

Set keys = sessionConcurrentMap.keySet();

for (String key : keys) {

Session session = SESSION_CACHE.getIfPresent(key);

DataTypePushWebSocket.sendMessage(message,session);

}

return AjaxResult.success();

}

}

至此websocket服务端代码已经完成。

stomp协议

前端代码.这个是在某个vue工程中写的js，各位大佬自己动手改改即可。其中Settings.wsPath是后端定义的ws地址例如ws://localhost:9003/ws

import Stomp from 'stompjs'

import Settings from '@/settings.js'

export default {

// 是否启用日志 默认启用

debug:true,

// 客户端连接信息

stompClient:{},

// 初始化

init(callBack){

this.stompClient = Stomp.client(Settings.wsPath)

this.stompClient.hasDebug = this.debug

this.stompClient.connect({},suce =>{

this.console("连接成功,信息如下 ↓")

this.console(this.stompClient)

if(callBack){

callBack()

}

},err => {

if(err) {

this.console("连接失败,信息如下 ↓")

this.console(err)

}

})

},

// 订阅

sub(address,callBack){

if(!this.stompClient.connected){

this.console("没有连接,无法订阅")

return

}

// 生成 id

let timestamp= new Date().getTime() + address

this.console("订阅成功 -> "+address)

this.stompClient.subscribe(address,message => {

this.console(address+" 订阅消息通知,信息如下 ↓")

this.console(message)

let data = message.body

callBack(data)

},{

id: timestamp

})

},

unSub(address){

if(!this.stompClient.connected){

this.console("没有连接,无法取消订阅 -> "+address)

return

}

let id = ""

for(let item in this.stompClient.subscriptions){

if(item.endsWith(address)){

id = item

break

}

}

this.stompClient.unsubscribe(id)

this.console("取消订阅成功 -> id:"+ id + " address:"+address)

},

// 断开连接

disconnect(callBack){

if(!this.stompClient.connected){

this.console("没有连接,无法断开连接")

return

}

this.stompClient.disconnect(() =>{

console.log("断开成功")

if(callBack){

callBack()

}

})

},

// 单位 秒

reconnect(time){

setInterval(() =>{

if(!this.stompClient.connected){

this.console("重新连接中...")

this.init()

}

},time * 1000)

},

console(msg){

if(this.debug){

console.log(msg)

}

},

// 向订阅发送消息

send(address,msg) {

this.stompClient.send(address,{},msg)

}

}

后端stomp config,里面都有注释，写的很详细,并且我加入了和前端的心跳ping pong。

package com-.scott.config;

import org.springframework.context.annotation.Configuration;

import org.springframework.messaging.simp.config.MessageBrokerRegistry;

import org.springframework.scheduling.concurrent.ThreadPoolTaskScheduler;

import org.springframework.web.socket.config.annotation.EnableWebSocketMessageBroker;

import org.springframework.web.socket.config.annotation.StompEndpointRegistry;

import org.springframework.web.socket.config.annotation.WebSocketMessageBrokerConfigurer;

/**

* @ClassName: WebSocketStompConfig

* @Author: scott

* @Date: 2021/7/8

**/

@Configuration

@EnableWebSocketMessageBroker

public class WebSocketStompConfig implements WebSocketMessageBrokerConfigurer {

private static long HEART_BEAT=10000;

@Override

public void registerStompEndpoints(StompEndpointRegistry registry) {

//允许使用socketJs方式访问，访问点为webSocket，允许跨域

//在网页上我们就可以通过这个链接

//ws://127.0.0.1:port/ws来和服务器的WebSocket连接

registry.addEndpoint("/ws").setAllowedOrigins("*");

}

@Override

public void configureMessageBroker(MessageBrokerRegistry registry) {

ThreadPoolTaskScheduler te = new ThreadPoolTaskScheduler();

te.setPoolSize(1);

te.setThreadNamePrefix("wss-heartbeat-thread-");

te.initialize();

//基于内存的STOMP消息代理来代替mq的消息代理

//订阅Broker名称,/user代表点对点即发指定用户，/topic代表发布广播即群发

//setHeartbeatValue 设置心跳及心跳时间

registry.enableSimpleBroker("/user", "/topic").setHeartbeatValue(new long[]{HEART_BEAT,HEART_BEAT}).setTaskScheduler(te);

//点对点使用的订阅前缀，不设置的话，默认也是/user/

registry.setUserDestinationPrefix("/user/");

}

}

后端stomp协议接受、订阅等动作通知

package com-.scott.ws;

import com.alibaba.fastjson.JSON;

import org.springframework.beans.factory.annotation.Autowired;

import org.springframework.messaging.handler.annotation.DestinationVariable;

import org.springframework.messaging.handler.annotation.MessageMapping;

import org.springframework.messaging.simp.SimpMessagingTemplate;

import org.springframework.messaging.simp.annotation.SubscribeMapping;

import org.springframework.web.bind.annotation.RestController;

/**

* @ClassName StompSocketHandler

* @Author scott

* @Date 2021/6/30

* @Version V1.0

**/

@RestController

public class StompSocketHandler {

@Autowired

private SimpMessagingTemplate simpMessagingTemplate;

/**

* @MethodName: subscribeMapping

* @Description: 订阅成功通知

* @Param: [id]

* @Return: void

* @Author: scott

* @Date: 2021/6/30

**/

@SubscribeMapping("/user/{id}/listener")

public void subscribeMapping(@DestinationVariable("id") final long id) {

System.out.println(">>>>>>用户:"+id +",已订阅");

SubscribeMsg param = new SubscribeMsg(id,String.format("用户【%s】已订阅成功", id));

sendToUser(param);

}

/**

* @MethodName: test

* @Description: 接收订阅topic消息

* @Param: [id, msg]

* @Return: void

* @Author: scott

* @Date: 2021/6/30

**/

@MessageMapping(value = "/user/{id}/listener")

public void UserSubListener(@DestinationVariable long id, String msg) {

System.out.println("收到客户端:" +id+",的消息");

SubscribeMsg param = new SubscribeMsg(id,String.format("已收到用户【%s】发送消息【%s】", id,msg));

sendToUser(param);

}

@GetMapping("/refresh/{userId}")

public void refresh(@PathVariable Long userId, String msg) {

StompSocketHandler.SubscribeMsg param = new StompSocketHandler.SubscribeMsg(userId,String.format("服务端向用户【%s】发送消息【%s】", userId,msg));

sendToUser(param);

}

/**

* @MethodName: sendToUser

* @Description: 推送消息给订阅用户

* @Param: [userId]

* @Return: void

* @Author: scott

* @Date: 2021/6/30

**/

public void sendToUser(SubscribeMsg screenChangeMsg){

//这里可以控制权限等。。。

simpMessagingTemplate.convertAndSendToUser(screenChangeMsg.getUserId().toString(),"/listener", JSON.toJSONString(screenChangeMsg));

}

/**

* @MethodName: sendBroadCast

* @Description: 发送广播，需要用户事先订阅广播

* @Param: [topic, msg]

* @Return: void

* @Author: scott

* @Date: 2021/6/30

**/

public void sendBroadCast(String topic,String msg){

simpMessagingTemplate.convertAndSend(topic,msg);

}

/**

* @ClassName: SubMsg

* @Author: scott

* @Date: 2021/6/30

**/

public static class SubscribeMsg {

private Long userId;

private String msg;

public SubscribeMsg(Long UserId, String msg){

this.userId = UserId;

this.msg = msg;

}

public Long getUserId() {

return userId;

}

public String getMsg() {

return msg;

}

}

}

连接展示

建立连接成功，这里可以看出是基于websocket协议

连接信息

ping pong

调用接口向订阅用户1发送消息,http://localhost:9003/refresh/1?msg=HelloStomp,可以在客户端控制台查看已经收到了消息。这个时候不同用户通过自己的userId可以区分订阅的主题，可以做到通过userId精准的往客户端推送消息。

还记得我们在后端配置的时候还指定了广播的订阅主题/topic，这时我们前端通过js只要订阅了这个主题，那么后端在像这个主题推送消息时，所有订阅的客户端都能收到，感兴趣的小伙伴可以自己试试，api我都写好了。

至此，实战完毕，喜欢的小伙伴麻烦关注加点赞。

springboot + stomp后端源码地址:https://gitee.com/ErGouGeSiBaKe/stomp-server
