Hadoop源码分析三启动及脚本剖析
Hadoop源码分析三启动及脚本剖析
1、 启动
hadoop的启动是通过其sbin目录下的脚本来启动的。与启动相关的叫脚本有以下几个：
start-all.sh、start-dfs.sh、start-yarn.sh、hadoop-daemon.sh、yarn-daemon.sh。
hadoop-daemon.sh是用来启动与hdfs相关的服务的
yarn-daemon.sh是用来启动和yarn相关的服务
start-dfs.sh是用来启动hdfs集群的
start-yarn.sh是用来启动yarn集群
start-all.sh是用来启动yarn和hdfs集群的
这几个start开头的脚本都是通过调用那两个daemon脚本来启动的。
2、 脚本分析
这里先从start-all.sh开始分析，然后逐步分析其脚本的调用。
start-all.sh脚本内容如下：
#!/usr/bin/env bash
# Licensed to the Apache Software Foundation (ASF) under one or more
# contributor license agreements. See the NOTICE file distributed with
# this work for additional information regarding copyright ownership.
# The ASF licenses this file to You under the Apache License, Version 2.0
# (the "License"); you may not use this file except in compliance with
# the License. You may obtain a copy of the License at
#
# http://apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
# Start all hadoop daemons. Run this on master node.
echo "This script is Deprecated. Instead use start-dfs.sh and start-yarn.sh"
bin=`dirname "${BASH_SOURCE-$0}"`
bin=`cd "$bin"; pwd`
DEFAULT_LIBEXEC_DIR="$bin"/../libexec
HADOOP_LIBEXEC_DIR=${HADOOP_LIBEXEC_DIR:-$DEFAULT_LIBEXEC_DIR}
. $HADOOP_LIBEXEC_DIR/hadoop-config.sh
# start hdfs daemons if hdfs is present
if [ -f "${HADOOP_HDFS_HOME}"/sbin/start-dfs.sh ]; then
"${HADOOP_HDFS_HOME}"/sbin/start-dfs.sh --config $HADOOP_CONF_DIR
fi
# start yarn daemons if yarn is present
if [ -f "${HADOOP_YARN_HOME}"/sbin/startImjxFzypZj-yarn.sh ]; then
"${HADOOP_YARN_HOME}"/sbin/start-yarn.sh --config $HADOOP_CONF_DIR
fi
这个脚本的重点在第31行到末尾，这里是两个if语句，第一个if语句里（第34行）调用的是start-dfs.sh脚本，第二个if语句里（第37行）调用的是start-yarn.sh。
然后我们以start-dfs.sh为例，继续向下分析。
start-dfs.sh的内容如下：
#!/usr/bin/env bash
# Licensed to the Apache Software Foundation (ASF) under one or more
# contributor license agreements. See the NOTICE file distributed with
# this work for additional information regarding copyright ownership.
# The ASF licenses this file to You under the Apache License, Version 2.0
# (the "License"); you may not use this file except in compliance with
# the License. You may obtain a copy of the License at
#
# http://apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
# Start hadoop dfs daemons.
# Optinally upgrade or rollback dfs state.
# Run this on master node.
usage="Usage: start-dfs.sh [-upgrade|-rollback] [other options such as -clusterId]"
bin=`dirname "${BASH_SOURCE-$0}"`
bin=`cd "$bin"; pwd`
DEFAULT_LIBEXEC_DIR="$bin"/../libexec
HADOOP_LIBEXEC_DIR=${HADOOP_LIBEXEC_DIR:-$DEFAULT_LIBEXEC_DIR}
. $HADOOP_LIBEXEC_DIR/hdfs-config.sh
# get arguments
if [[ $# -ge 1 ]]; then
startOpt="$1"
shift
case "$startOpt" in
-upgrade)
nameStartOpt="$startOpt"
;;
-rollback)
dataStartOpt="$startOpt"
;;
*)
echo $usage
exit 1
;;
esac
fi
#Add other possible options
nameStartOpt="$nameStartOpt $@"
#---------------------------------------------------------
# namenodes
NAMENODES=$($HADOOP_PREFIX/bin/hdfs getconf -namenodes)
echo "Starting namenodes on [$NAMENODES]"
"$HADOOP_PREFIX/sbin/hadoop-daemons.sh" \
--config "$HADOOP_CONF_DIR" \
--hostnames "$NAMENODES" \
--script "$bin/hdfs" start namenode $nameStartOpt
#---------------------------------------------------------
# datanodes (using default slaves file)
if [ -n "$HADOOP_SECURE_DN_USER" ]; then
echo \
"Attempting to start secure cluster, skipping datanodes. " \
"Run start-secure-dns.sh as root to complete startup."
else
"$HADOOP_PREFIX/sbin/hadoop-daemons.sh" \
--config "$HADOOP_CONF_DIR" \
--script "$bin/hdfs" start datanode $dataStartOpt
fi
#---------------------------------------------------------
# secondary namenodes (if any)
SECONDARY_NAMENODES=$($HADOOP_PREFIX/bin/hdfs getconf -secondarynamenodes 2>/dev/null)
if [ -n "$SECONDARY_NAMENODES" ]; then
echo "Starting secondary namenodes [$SECONDARY_NAMENODES]"
"$HADOOP_PREFIX/sbin/hadoop-daemons.sh" \
--config "$HADOOP_CONF_DIR" \
--hostnames "$SECONDARY_NAMENODES" \
--script "$bin/hdfs" start secondarynamenode
fi
#---------------------------------------------------------
# quorumjournal nodes (if any)
SHARED_EDITS_DIR=$($HADOOP_PREFIX/bin/hdfs getconf -confKey dfs.namenode.shared.edits.dir 2>&-)
case "$SHARED_EDITS_DIR" in
qjournal://*)
JOURNAL_NODES=$(echo "$SHARED_EDITS_DIR" | sed 's,qjournal://\([^/]*\)/.*,\1,g; s/;/ /g; s/:[0-9]*//g')
echo "Starting journal nodes [$JOURNAL_NODES]"
"$HADOOP_PREFIX/sbin/hadoop-daemons.sh" \
--config "$HADOOP_CONF_DIR" \
--hostnames "$JOURNAL_NODES" \
--script "$bin/hdfs" start journalnode ;;
esac
#---------------------------------------------------------
# ZK Failover controllers, if auto-HA is enabled
AUTOHA_ENABLED=$($HADOOP_PREFIX/bin/hdfs getconf -confKey dfs.ha.automatic-failover.enabled)
if [ "$(echo "$AUTOHA_ENABLED" | tr A-Z a-z)" = "true" ]; then
echo "Starting ZK Failover Controllers on NN hosts [$NAMENODES]"
"$HADOOP_PREFIX/sbin/hadoop-daemons.sh" \
--config "$HADOOP_CONF_DIR" \
--hostnames "$NAMENODES" \
--script "$bin/hdfs" start zkfc
fi
# eof
首先是第23行到30行，这里是在处理hadoop的路径。
然后是第32行到51行是在处理脚本传入的参数。最后就启动hdfs的各个角色了。
首先启动的是namenode，在第60行到63行，这段代码是调用了hadoop-daemons.sh脚本来启动，这个脚本和之前提到的hadoop-daemon.sh脚本的区别在于这个脚本可以在集群的其他机器上启动该启动的角色，而hadoop-daemon.sh只能启动当前机器上的角色。其实hadoop-daemons.sh也是通过调用hadoop-daemon.sh来启动的，这个稍后再分析。这个脚本还有几个参数，其中最重要的是：start namenode。它表示启动namenode。
然后是第65行到第76行，这里是在启动datanode，启动的方式和namenode相同。启动DataNode的代码在第73行。
然后是第78行到第90行，这里在启动secondarynamenode。如果是配置了namenode的高可用，secondarynamenode便不会启动。
然后是第92行到第105行，这里在启动journalnode。如果配置了namenode的高可用，journalnode才会启动。
最后是第107行到末尾，这里启动的是zkfc。同样这个也是要配置高可用才会启动。
如果按照文档（2）中配置的高可用来看，这里启动的角色应该为：namenode、datanode、journalnode、zkfc。
启动上述角色调用的hadoop-daemons.sh脚本内容如下：
#!/usr/bin/env bash
# Licensed to the Apache Software Foundation (ASF) under one or more
# contributor license agreements. See the NOTICE file distributed with
# this work for additional information regarding copyright ownership.
# The ASF licenses this file to You under the Apache License, Version 2.0
# (the "License"); you may not use this file except in compliance with
# the License. You may obtain a copy of the License at
#
# http://apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
# Run a Hadoop command on all slave hosts.
usage="Usage: hadoop-daemons.sh [--config confdir] [--hosts hostlistfile] [start|stop] command args..."
# if no args specified, show usage
if [ $# -le 1 ]; then
echo $usage
exit 1
fi
bin=`dirname "${BASH_SOURCE-$0}"`
bin=`cd "$bin"; pwd`
DEFAULT_LIBEXEC_DIR="$bin"/../libexec
HADOOP_LIBEXEC_DIR=${HADOOP_LIBEXEC_DIR:-$DEFAULT_LIBEXEC_DIR}
. $HADOOP_LIBEXEC_DIR/hadoop-config.sh
exec "$bin/slaves.sh" --config $HADOOP_CONF_DIR cd "$HADOOP_PREFIX" \; "$bin/hadoop-daemon.sh" --config $HADOOP_CONF_DIR "$@"
这个脚本的重点在最后一行。这里有两个脚本slaves.sh和hadoop-daemon.sh。slaves.sh脚本会使用ssh登录到指定的服务器中然后执行其中的hadoop-daemon.sh脚本。这里就不分析slaves.sh脚本了。
我们继续看hadoop-daemon.sh脚本。
其内容如下：
#!/usr/bin/env bash
# Licensed to the Apache Software Foundation (ASF) under one or more
# contImjxFzypZjributor license agreements. See the NOTICE file distributed with
# this work for additional information regarding copyright ownership.
# The ASF licenses this file to You under the Apache License, Version 2.0
# (the "License"); you may not use this file except in compliance with
# the License. You may obtain a copy of the License at
#
# http://apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
# Runs a Hadoop command as a daemon.
#
# Environment Variables
#
# HADOOP_CONF_DIR Alternate conf dir. Default is ${HADOOP_PREFIX}/conf.
# HADOOP_LOG_DIR Where log files are stored. PWD by default.
# HADOOP_MASTER host:path where hadoop code should be rsync'd from
# HADOOP_PID_DIR The pid files are stored. /tmp by default.
# HADOOP_IDENT_STRING A string representing this instance of hadoop. $USER by default
# HADOOP_NICENESS The scheduling priority for daemons. Defaults to 0.
##
usage="Usage: hadoop-daemon.sh [--config
# if no args specified, show usage
if [ $# -le 1 ]; then
echo $usage
exit 1
fi
bin=`dirname "${BASH_SOURCE-$0}"`
bin=`cd "$bin"; pwd`
DEFAULT_LIBEXEC_DIR="$bin"/../libexec
HADOOP_LIBEXEC_DIR=${HADOOP_LIBEXEC_DIR:-$DEFAULT_LIBEXEC_DIR}
. $HADOOP_LIBEXEC_DIR/hadoop-config.sh
# get arguments
#default value
hadoopScript="$HADOOP_PREFIX"/bin/hadoop
if [ "--script" = "$1" ]
then
shift
hadoopScript=$1
shift
fi
startStop=$1
shift
command=$1
shift
hadoop_rotate_log ()
{
log=$1;
num=5;
if [ -n "$2" ]; then
num=$2
fi
if [ -f "$log" ]; then # rotate logs
while [ $num -gt 1 ]; do
prev=`expr $num - 1`
[ -f "$log.$prev" ] && mv "$log.$prev" "$log.$num"
num=$prev
done
mv "$log" "$log.$num";
fi
}
if [ -f "${HADOOP_CONF_DIR}/hadoop-env.sh" ]; then
. "${HADOOP_CONF_DIR}/hadoop-env.sh"
fi
# Determine if we're starting a secure datanode, and if so, redefine appropriate variables
if [ "$command" == "datanode" ] && [ "$EUID" -eq 0 ] && [ -n "$HADOOP_SECURE_DN_USER" ]; then
export HADOOP_PID_DIR=$HADOOP_SECURE_DN_PID_DIR
export HADOOP_LOG_DIR=$HADOOP_SECURE_DN_LOG_DIR
export HADOOP_IDENT_STRING=$HADOOP_SECURE_DN_USER
starting_secure_dn="true"
fi
#Determine if we're starting a privileged NFS, if so, redefine the appropriate variables
if [ "$command" == "nfs3" ] && [ "$EUID" -eq 0 ] && [ -n "$HADOOP_PRIVILEGED_NFS_USER" ]; then
export HADOOP_PID_DIR=$HADOOP_PRIVILEGED_NFS_PID_DIR
export HADOOP_LOG_DIR=$HADOOP_PRIVILEGED_NFS_LOG_DIR
export HADOOP_IDENT_STRING=$HADOOP_PRIVILEGED_NFS_USER
starting_privileged_nfs="true"
fi
if [ "$HADOOP_IDENT_STRING" = "" ]; then
export HADOOP_IDENT_STRING="$USER"
fi
# get log directory
if [ "$HADOOP_LOG_DIR" = "" ]; then
export HADOOP_LOG_DIR="$HADOOP_PREFIX/logs"
fi
if [ ! -w "$HADOOP_LOG_DIR" ] ; then
mkdir -p "$HADOOP_LOG_DIR"
chown $HADOOP_IDENT_STRING $HADOOP_LOG_DIR
fi
if [ "$HADOOP_PID_DIR" = "" ]; then
HADOOP_PID_DIR=/tmp
fi
# some variables
export HADOOP_LOGFILE=hadoop-$HADOOP_IDENT_STRING-$command-$HOSTNAME.log
export HADOOP_ROOT_LOGGER=${HADOOP_ROOT_LOGGER:-"INFO,RFA"}
export HADOOP_SECURITY_LOGGER=${HADOOP_SECURITY_LOGGER:-"INFO,RFAS"}
export HDFS_AUDIT_LOGGER=${HDFS_AUDIT_LOGGER:-"INFO,NullAppender"}
log=$HADOOP_LOG_DIR/hadoop-$HADOOP_IDENT_STRING-$command-$HOSTNAME.out
pid=$HADOOP_PID_DIR/hadoop-$HADOOP_IDENT_STRING-$command.pid
HADOOP_STOP_TIMEOUT=${HADOOP_STOP_TIMEOUT:-5}
# Set default scheduling priority
if [ "$HADOOP_NICENESS" = "" ]; then
export HADOOP_NICENESS=0
fi
case $startStop in
(start)
[ -w "$HADOOP_PID_DIR" ] || mkdir -p "$HADOOP_PID_DIR"
if [ -f $pid ]; then
if kill -0 `cat $pid` > /dev/null 2>&1; then
echo $command running as process `cat $pid`. Stop it first.
exit 1
fi
fi
if [ "$HADOOP_MASTER" != "" ]; then
echo rsync from $HADOOP_MASTER
rsync -a -e ssh --delete --exclude=.svn --exclude='logs/*' --exclude='contrib/hod/logs/*' $HADOOP_MASTER/ "$HADOOP_PREFIX"
fi
hadoop_rotate_log $log
echo starting $command, logging to $log
cd "$HADOOP_PREFIX"
case $command in
namenode|secondarynamenode|datanode|journalnode|dfs|dfsadmin|fsck|balancer|zkfc)
if [ -z "$HADOOP_HDFS_HOME" ]; then
hdfsScript="$HADOOP_PREFIX"/bin/hdfs
else
hdfsScript="$HADOOP_HDFS_HOME"/bin/hdfs
fi
nohup nice -n $HADOOP_NICENESS $hdfsScript --config $HADOOP_CONF_DIR $command "$@" > "$log" 2>&1 < /dev/null &
;;
(*)
nohup nice -n $HADOOP_NICENESS $hadoopScript --config $HADOOP_CONF_DIR $command "$@" > "$log" 2>&1 < /dev/null &
;;
esac
echo $! > $pid
sleep 1
head "$log"
# capture the ulimit output
if [ "true" = "$starting_secure_dn" ]; then
echo "ulimit -a for secure datanode user $HADOOP_SECURE_DN_USER" >> $log
# capture the ulimit info for the appropriate user
su --shell=/bin/bash $HADOOP_SECURE_DN_USER -c 'ulimit -a' >> $log 2>&1
elif [ "true" = "$starting_privileged_nfs" ]; then
echo "ulimit -a for privileged nfs user $HADOOP_PRIVILEGED_NFS_USER" >> $log
su --shell=/bin/bash $HADOOP_PRIVILEGED_NFS_USER -c 'ulimit -a' >> $log 2>&1
else
echo "ulimit -a for user $USER" >> $log
ulimit -a >> $log 2>&1
fi
sleep 3;
if ! ps -p $! > /dev/null ; then
exit 1
fi
;;
(stop)
if [ -f $pid ]; then
TARGET_PID=`cat $pid`
if kill -0 $TARGET_PID > /dev/null 2>&1; then
echo stopping $command
kill $TARGET_PID
sleep $HADOOP_STOP_TIMEOUT
if kill -0 $TARGET_PID > /dev/null 2>&1; then
echo "$command did not stop gracefully after $HADOOP_STOP_TIMEOUT seconds: killing with kill -9"
kill -9 $TARGET_PID
fi
else
echo no $command to stop
fi
rm -f $pid
else
echo no $command to stop
fi
;;
(*)
echo $usage
exit 1
;;
esac
这段代码的重点在第131行到结束。这里是真正在启动服务的代码，这个文件在调用的时候，会传入两个重要的参数start/stop xxx。用于启动或停止某些服务。以启动服务为例，其重点在第153行，这里会执行一个hdfsScript脚本。这个参数的定义在第155行，
这里可以看见它实际是hadoop的bin目录下的hdfs文件
文件的内容如下：
#!/usr/bin/env bash
# Licensed to the Apache Software Foundation (ASF) under one or more
# contributor license agreements. See the NOTICE file distributed with
# this work for additional information regarding copyright ownership.
# The ASF licenses this file to You under the Apache License, Version 2.0
# (the "License"); you may not use this file except in compliance with
# the License. You may obtain a copy of the License at
#
# http://apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
# Environment Variables
#
# jsVC_HOME home directory of jsvc binary. Required for starting secure
# datanode.
#
# JSVC_OUTFILE path to jsvc output file. Defaults to
# $HADOOP_LOG_DIR/jsvc.out.
#
# JSVC_ERRFILE path to jsvc error file. Defaults to $HADOOP_LOG_DIR/jsvc.err.
bin=`which $0`
bin=`dirname ${bin}`
bin=`cd "$bin" > /dev/null; pwd`
DEFAULT_LIBEXEC_DIR="$bin"/../libexec
HADOOP_LIBEXEC_DIR=${HADOOP_LIBEXEC_DIR:-$DEFAULT_LIBEXEC_DIR}
. $HADOOP_LIBEXEC_DIR/hdfs-config.sh
function print_usage(){
echo "Usage: hdfs [--config confdir] [--loglevel loglevel] COMMAND"
echo " where COMMAND is one of:"
echo " dfs run a filesystem command on the file systems supported in Hadoop."
echo " classpath prints the classpath"
echo " namenode -format format the DFS filesystem"
echo " secondarynamenode run the DFS secondary namenode"
echo " namenode run the DFS namenode"
echo " journalnode run the DFS journalnode"
echo " zkfc run the ZK Failover Controller daemon"
echo " datanode run a DFS datanode"
echo " dfsadmin run a DFS admin client"
echo " haadmin run a DFS HA admin client"
echo " fsck run a DFS filesystem checking utility"
echo " balancer run a cluster balancing utility"
echo " jmxget get JMX exported values from NameNode or DataNode."
echo " mover run a utility to move block replicas across"
echo " storage types"
echo " oiv apply the offline fsimage viewer to an fsimage"
echo " oiv_legacy apply the offline fsimage viewer to an legacy fsimage"
echo " oev apply the offline edits viewer to an edits file"
echo " fetchdt fetch a delegation token from the NameNode"
echo " getconf get config values from configuration"
echo " groups get the groups which users belong to"
echo " snapshotDiff diff two snapshots of a directory or diff the"
echo " current directory contents with a snapshot"
echo " lsSnapshottableDir list all snapshottable dirs owned by the current user"
echo " Use -help to see options"
echo " portmap run a portmap service"
echo " nfs3 run an NFS version 3 gateway"
echo " cacheadmin configure the HDFS cache"
echo " crypto configure HDFS encryption zones"
echo " storagepolicies list/get/set block storage policies"
echo " version print the version"
echo ""
echo "Most commands print help when invoked w/o parameters."
# There are also debug commands, but they don't show up in this listing.
}
if [ $# = 0 ]; then
print_usage
exit
fi
COMMAND=$1
shift
case $COMMAND in
# usage flags
--help|-help|-h)
print_usage
exit
;;
esac
# Determine if we're starting a secure datanode, and if so, redefine appropriate variables
if [ "$COMMAND" == "datanode" ] && [ "$EUID" -eq 0 ] && [ -n "$HADOOP_SECURE_DN_USER" ]; then
if [ -n "$JSVC_HOME" ]; then
if [ -n "$HADOOP_SECURE_DN_PID_DIR" ]; then
HADOOP_PID_DIR=$HADOOP_SECURE_DN_PID_DIR
fi
if [ -n "$HADOOP_SECURE_DN_LOG_DIR" ]; then
HADOOP_LOG_DIR=$HADOOP_SECURE_DN_LOG_DIR
HADOOP_OPTS="$HADOOP_OPTS -Dhadoop.log.dir=$HADOOP_LOG_DIR"
fi
HADOOP_IDENT_STRING=$HADOOP_SECURE_DN_USER
HADOOP_OPTS="$HADOOP_OPTS -Dhadoop.id.str=$HADOOP_IDENT_STRING"
starting_secure_dn="true"
else
echo "It looks like you're trying to start a secure DN, but \$JSVC_HOME"\
"isn't set. Falling back to starting insecure DN."
fi
fi
# Determine if we're starting a privileged NFS daemon, and if so, redefine appropriate variables
if [ "$COMMAND" == "nfs3" ] && [ "$EUID" -eq 0 ] && [ -n "$HADOOP_PRIVILEGED_NFS_USER" ]; then
if [ -n "$JSVC_HOME" ]; then
if [ -n "$HADOOP_PRIVILEGED_NFS_PID_DIR" ]; then
HADOOP_PID_DIR=$HADOOP_PRIVILEGED_NFS_PID_DIR
fi
if [ -n "$HADOOP_PRIVILEGED_NFS_LOG_DIR" ]; then
HADOOP_LOG_DIR=$HADOOP_PRIVILEGED_NFS_LOG_DIR
HADOOP_OPTS="$HADOOP_OPTS -Dhadoop.log.dir=$HADOOP_LOG_DIR"
fi
HADOOP_IDENT_STRING=$HADOOP_PRIVILEGED_NFS_USER
HADOOP_OPTS="$HADOOP_OPTS -Dhadoop.id.str=$HADOOP_IDENT_STRING"
starting_privileged_nfs="true"
else
echo "It looks like you're trying to start a privileged NFS server, but"\
"\$JSVC_HOME isn't set. Falling back to starting unprivileged NFS server."
fi
fi
if [ "$COMMAND" = "namenode" ] ; then
CLASS='org.apache.hadoop.hdfshttp://.server.namenode.NameNode'
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_NAMENODE_OPTS"
elif [ "$COMMAND" = "zkfc" ] ; then
CLASS='org.apache.hadoop.hdfs.tools.DFSZKFailoverController'
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_ZKFC_OPTS"
elif [ "$COMMAND" = "secondarynamenode" ] ; then
CLASS='org.apache.hadoop.hdfs.server.namenode.SecondaryNameNode'
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_SECONDARYNAMENODE_OPTS"
elif [ "$COMMAND" = "datanode" ] ; then
CLASS='org.apache.hadoop.hdfs.server.datanode.DataNode'
if [ "$starting_secure_dn" = "true" ]; then
HADOOP_OPTS="$HADOOP_OPTS -jvm server $HADOOP_DATANODE_OPTS"
else
HADOOP_OPTS="$HADOOP_OPTS -server $HADOOP_DATANODE_OPTS"
fi
elif [ "$COMMAND" = "journalnode" ] ; then
CLASS='org.apache.hadoop.hdfs.qjournal.server.JournalNode'
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_JOURNALNODE_OPTS"
elif [ "$COMMAND" = "dfs" ] ; then
CLASS=org.apache.hadoop.fs.FsShell
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_CLIENT_OPTS"
elif [ "$COMMAND" = "dfsadmin" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.DFSAdmin
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_CLIENT_OPTS"
elif [ "$COMMAND" = "haadmin" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.DFSHAAdmin
CLASSPATH=${CLASSPATH}:${TOOL_PATH}
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_CLIENT_OPTS"
elif [ "$COMMAND" = "fsck" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.DFSck
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_CLIENT_OPTS"
elif [ "$COMMAND" = "balancer" ] ; then
CLASS=org.apache.hadoop.hdfs.server.balancer.Balancer
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_BALANCER_OPTS"
elif [ "$COMMAND" = "mover" ] ; then
CLASS=org.apache.hadoop.hdfs.server.mover.Mover
HADOOP_OPTS="${HADOOP_OPTS} ${HADOOP_MOVER_OPTS}"
elif [ "$COMMAND" = "storagepolicies" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.StoragePolicyAdmin
elif [ "$COMMAND" = "jmxget" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.JMXGet
elif [ "$COMMAND" = "oiv" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.offlineImageViewer.OfflineImageViewerPB
elif [ "$COMMAND" = "oiv_legacy" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.offlineImageViewer.OfflineImageViewer
elif [ "$COMMAND" = "oev" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.offlineEditsViewer.OfflineEditsViewer
elif [ "$COMMAND" = "fetchdt" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.DelegationTokenFetcher
elif [ "$COMMAND" = "getconf" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.GetConf
elif [ "$COMMAND" = "groups" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.GetGroups
elif [ "$COMMAND" = "snapshotDiff" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.snapshot.SnapshotDiff
elif [ "$COMMAND" = "lsSnapshottableDir" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.snapshot.LsSnapshottableDir
elif [ "$COMMAND" = "portmap" ] ; then
CLASS=org.apache.hadoop.portmap.Portmap
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_PORTMAP_OPTS"
elif [ "$COMMAND" = "nfs3" ] ; then
CLASS=org.apache.hadoop.hdfs.nfs.nfs3.Nfs3
HADOOP_OPTS="$HADOOP_OPTS $HADOOP_NFS3_OPTS"
elif [ "$COMMAND" = "cacheadmin" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.CacheAdmin
elif [ "$COMMAND" = "crypto" ] ; then
CLASS=org.apache.hadoop.hdfs.tools.CryptoAdmin
elif [ "$COMMAND" = "version" ] ; then
CLASS=org.apache.hadoop.util.VersionInfo
elif [ "$COMMAND" = "debug" ]; then
CLASS=org.apache.hadoop.hdfs.tools.DebugAdmin
elif [ "$COMMAND" = "classpath" ]; then
if [ "$#" -gt 0 ]; then
CLASS=org.apache.hadoop.util.Classpath
else
# No need to bother starting up a JVM for this simple case.
if $cygwin; then
CLASSPATH=$(cygpath -p -w "$CLASSPATH" 2>/dev/null)
fi
echo $CLASSPATH
exit 0
fi
else
CLASS="$COMMAND"
fi
# cygwin path translation
if $cygwin; then
CLASSPATH=$(cygpath -p -w "$CLASSPATH" 2>/dev/null)
HADOOP_LOG_DIR=$ImjxFzypZj(cygpath -w "$HADOOP_LOG_DIR" 2>/dev/null)
HADOOP_PREFIX=$(cygpath -w "$HADOOP_PREFIX" 2>/dev/null)
HADOOP_CONF_DIR=$(cygpath -w "$HADOOP_CONF_DIR" 2>/dev/null)
HADOOP_COMMON_HOME=$(cygpath -w "$HADOOP_COMMON_HOME" 2>/dev/null)
HADOOP_HDFS_HOME=$(cygpath -w "$HADOOP_HDFS_HOME" 2>/dev/null)
HADOOP_YARN_HOME=$(cygpath -w "$HADOOP_YARN_HOME" 2>/dev/null)
HADOOP_MAPRED_HOME=$(cygpath -w "$HADOOP_MAPRED_HOME" 2>/dev/null)
fi
export CLASSPATH=$CLASSPATH
HADOOP_OPTS="$HADOOP_OPTS -Dhadoop.security.logger=${HADOOP_SECURITY_LOGGER:-INFO,NullAppender}"
# Check to see if we should start a secure datanode
if [ "$starting_secure_dn" = "true" ]; then
if [ "$HADOOP_PID_DIR" = "" ]; then
HADOOP_SECURE_DN_PID="/tmp/hadoop_secure_dn.pid"
else
HADOOP_SECURE_DN_PID="$HADOOP_PID_DIR/hadoop_secure_dn.pid"
fi
JSVC=$JSVC_HOME/jsvc
if [ ! -f $JSVC ]; then
echo "JSVC_HOME is not set correctly so jsvc cannot be found. jsvc is required to run secure datanodes. "
echo "Please download and install jsvc from http://archive.apache.org/dist/commons/daemon/binaries/ "\
"and set JSVC_HOME to the directory containing the jsvc binary."
exit
fi
if [[ ! $JSVC_OUTFILE ]]; then
JSVC_OUTFILE="$HADOOP_LOG_DIR/jsvc.out"
fi
if [[ ! $JSVC_ERRFILE ]]; then
JSVC_ERRFILE="$HADOOP_LOG_DIR/jsvc.err"
fi
exec "$JSVC" \
-Dproc_$COMMAND -outfile "$JSVC_OUTFILE" \
-errfile "$JSVC_ERRFILE" \
-pidfile "$HADOOP_SECURE_DN_PID" \
-nodetach \
-user "$HADOOP_SECURE_DN_USER" \
-cp "$CLASSPATH" \
$java_HEAP_MAX $HADOOP_OPTS \
org.apache.hadoop.hdfs.server.datanode.SecureDataNodeStarter "$@"
elif [ "$starting_privileged_nfs" = "true" ] ; then
if [ "$HADOOP_PID_DIR" = "" ]; then
HADOOP_PRIVILEGED_NFS_PID="/tmp/hadoop_privileged_nfs3.pid"
else
HADOOP_PRIVILEGED_NFS_PID="$HADOOP_PID_DIR/hadoop_privileged_nfs3.pid"
fi
JSVC=$JSVC_HOME/jsvc
if [ ! -f $JSVC ]; then
echo "JSVC_HOME is not set correctly so jsvc cannot be found. jsvc is required to run privileged NFS gateways. "
echo "Please download and install jsvc from http://archive.apache.org/dist/commons/daemon/binaries/ "\
"and set JSVC_HOME to the directory containing the jsvc binary."
exit
fi
if [[ ! $JSVC_OUTFILE ]]; then
JSVC_OUTFILE="$HADOOP_LOG_DIR/nfs3_jsvc.out"
fi
if [[ ! $JSVC_ERRFILE ]]; then
JSVC_ERRFILE="$HADOOP_LOG_DIR/nfs3_jsvc.err"
fi
exec "$JSVC" \
-Dproc_$COMMAND -outfile "$JSVC_OUTFILE" \
-errfile "$JSVC_ERRFILE" \
-pidfile "$HADOOP_PRIVILEGED_NFS_PID" \
-nodetach \
-user "$HADOOP_PRIVILEGED_NFS_USER" \
-cp "$CLASSPATH" \
$JAVA_HEAP_MAX $HADOOP_OPTS \
org.apache.hadoop.hdfs.nfs.nfs3.PrivilegedNfsGatewayStarter "$@"
else
# run it
exec "$JAVA" -Dproc_$COMMAND $JAVA_HEAP_MAX $HADOOP_OPTS $CLASS "$@"
fi
这段代码的重点在第134行到219行和第304行。首先看第134行到219行，这段代码虽然很长但全是一堆if else语句。其逻辑也很简单，就是根据传入的COMMAND的值来为CLASS和HADOOP_OPTS赋值。然后是第304行，执行CLASS类。以第134行的namenode类为例，这里CLASS的值为org.apache.hadoop.hdfs.server.namenode.NameNode，这是一个java类随后便会执行这个类启动namenode。
如果想要debug hdfs的源码，最好在这里设置远程调试。因为这里有单个的服务类与启动参数，可以准确的定位需要的服务。
以上就是Hadoop源码分析之启动及脚本剖析的详细内容，更多关于Hadoop源码分析分析的资料请继续关注我们其它相关文章！
版权声明：本文内容由网络用户投稿，版权归原作者所有，本站不拥有其著作权，亦不承担相应法律责任。如果您发现本站中有涉嫌抄袭或描述失实的内容，请联系我们jiasou666@gmail.com 处理，核实后本网站将在24小时内删除侵权内容。
相关文章
发表评论
最近发表
- 洞察如何在鸿蒙系统环境下实现高效的小程序管理与安全合规
- 企业如何利用HarmonyOS开发工具提升小程序开发效率与合规性
- 洞察鸿蒙OS应用开发如何助力企业实现多元化小程序管理提升竞争力？
- 洞察纵观鸿蒙next版本，如何凭借FinClip加强小程序的跨平台管理，确保企业在数字化转型中的高效运营和数据安全？
- 洞察金融行业需要转型，如何利用鸿蒙app开发提升运营效率
- 如何通过FinClip的技术助力企业在信创办公平台实现高效合规管理和灵活应用
- 洞察在数字化转型过程中，信创推动企业有效整合资源，实现低成本、高效率的跨平台小程序运营。
- 洞察了解什么是信创国产化，如何通过小程序技术推动数字化转型，满足行业合规与多样化需求。
- 优化企业数字化转型，如何高效实现信创兼容适配，提升小程序管理与跨终端适配能力
- 洞察如何利用FinClip的小程序容器技术实现信创适配并推动数字化转型
推荐文章
热评文章
暂时没有评论，来抢沙发吧~
