Cambricon CNStream

CNStream is a streaming framework with plug-ins. It is used to connect other modules, includes basic functionalities, libraries, and essential elements.

CNStream provides the following plug-in modules:

source: Supports RTSP, video file, and images（H.264, H.265, and JPEG decoding.）inference: MLU-based inference accelerator for detection and classification.osd (On-screen display): Module for highlighting objects and text overlay.encode: Encodes on CPU.display: Display the video on screen.tracker: Multi-object tracking.

Cambricon Dependencies

CNStream depends on the CNCodec library and the CNRT library which are packed in Cambricon neuware package. Therefore, the lastest Cambricon neuware package is required. If you do not have one, please feel free to contact with us. Our mailbox: service@cambricon.com

Install Cambricon neuware package

Ubuntu or Debian

dpkg -i neuware-mluxxx-x.x.x_Ubuntuxx.xx_amd64.deb cd /var/neuware-mluxxx-x.x.x dpkg -i cncodec-xxx.deb cnrt_xxx.deb

Centos

yum -y install neuware-mluxxx-x.x.x.el7.x86_64.rpm cd /var/neuware-mluxxx-x.x.x yum -y install cncodec-xxx.rpm cnrt-xxx.rpm

After that, Cambricon dependencies that CNStream needed are installed at path '/usr/loacl/neuware'.

Please make sure you must not install cnstream_xxx.deb or cnstream-xxx.rpm.

Quick Start

This section introduces how to quickly build instructions on CNStream and how to develop your own applications based on CNStream. We strongly recommend you execute pre_required_helper.sh to prepare for the environment. If not, please follow the commands below.

Required environments

Before building instructions, you need to install the following software:

OpenCV2.4.9+GFlags2.1.2GLog0.3.4Cmake2.8.7+Live555 // If WITH_RTSP=ON, please run download_live.SDL22.0.4+ // If build_display=ON.

Ubuntu or Debian

If you are using Ubuntu or Debian, run the following commands:

OpenCV2.4.9+ >>>>>>>>> sudo apt-get install libopencv-dev GFlags2.1.2 >>>>>>>>> sudo apt-get install libgflags-dev GLog0.3.4 >>>>>>>>> sudo apt-get install libgoogle-glog-dev Cmake2.8.7+ >>>>>>>>> sudo apt-get install cmake SDL22.0.4+ >>>>>>>>> sudo apt-get install libsdl2-dev

Centos

If you are using Centos, run the following commands:

OpenCV2.4.9+ >>>>>>>>> sudo yum install opencv-devel.x86_64 GFlags2.1.2 >>>>>>>>> sudo yum install gflags.x86_64 GLog0.3.4 >>>>>>>>> sudo yum install glog.x86_64 Cmake2.8.7+ >>>>>>>>> sudo yum install cmake3.x86_64 SDL22.0.4+ >>>>>>>>> sudo yum install SDL2_gfx-devel.x86_64

Build Instructions Using CMake

After finished prerequisites, you can build instructions with the following steps:

1. Run the following command to save a directory for saving the output.

   mkdir build       # Create a directory to save the output.

   A Makefile is generated in the build folder.

2. Run the following command to generate a script for building instructions.

   cd buildcmake ${CNSTREAM_DIR}  # Generate native build scripts.

   Cambricon CNStream provides a CMake script (CMakeLists.txt) to build instructions. You can download CMake for free from http://cmake.org/.

   ${CNSTREAM_DIR} specifies the directory where CNStream saves for.

   cmake option	range	default	description
   build_display	ON / OFF	ON	build display module
   build_encode	ON / OFF	ON	build encode module
   build_inference	ON / OFF	ON	build inference module
   build_osd	ON / OFF	ON	build osd module
   build_source	ON / OFF	ON	build source module
   build_track	ON / OFF	ON	build track module
   build_perf	ON / OFF	ON	build performance statistics
   build_tests	ON / OFF	ON	build tests
   build_samples	ON / OFF	ON	build samples
   build_test_coverage	ON / OFF	OFF	build test coverage
   MLU	MLU270	MLU270	specify MLU platform
   RELEASE	ON / OFF	ON	release / debug
   WITH_FFMPEG	ON / OFF	ON	build with FFMPEG
   WITH_OPENCV	ON / OFF	ON	build with OPENCV
   WITH_CHINESE	ON / OFF	OFF	build with CHINESE
   WITH_RTSP	ON / OFF	ON	build with RTSP

3. If you want to build CNStream samples: a. Run the following command:

   cmake -Dbuild_samples=ON ${CNSTREAM_DIR}

   b. If wanna cross compile, please follow command to:

   cmake -DCMAKE_TOOLCHAIN_FILE=${CNSTREAM_DIR}/cmake/cross-compile.cmake ${CNSTREAM_DIR}

   Note: you need to configure toolchain by yourself in cross-compile.cmake

4. Run the following command to build instructions:

   make

Samples

Demo Overview

This demo shows how to detect objects using CNStream. It includes the following plug-in modules:

source: Decodes video streams with MLU, such as local video files, RTMP stream, and RTSP stream.inferencer: Neural Network inference with MLU.osd: Draws inference results on images.tracker: Tracks multi-objects.encoder: Encodes images with inference results, namely the detection result.displayer: Displays inference results on the screen.

In the run.sh script, detection_config.json is set as the configuration file. In this configuration file, resnet34_ssd.cambricon is the offline model used for inference, which means, the data will be fed to an SSD model after decoding. And the results will be shown on the screen.

If we build with build_perf on, the performance statistics of each plug-in module and the pipeline will be printed on the terminal.

In addition, see the comments in cnstream/samples/demo/run.sh for details.

Another script run_yolov3_mlu270.sh, is an example of Yolov3 implementation. The output will be encoded to AVI files, as an encoder plugin is added. The output directory can be specified by the [dump_dir] parameter. In this case, dump_dir is set to 'output', therefore AVI files can be found in the cnstream/samples/demo/output directory.

Run samples

To run the CNStream sample:

Follow the steps above to build instructions. Run the demo using the list below:cd ${CNSTREAM_DIR}/samples/demo./run.sh

Best Practices

How to create an application based on CNStream?

You should find a sample from samples/example/example.cpp that helps developers easily understand how to develop an application based on CNStream pipeline.

How to change the input video file?

Modify the files.list_video file, which is under the cnstream/samples/demo directory, to replace the video path. It is recommended to use an absolute path or use a relative path relative to the executor path.

How to adapt other networks than SSD?

Modify pre-processing(optional). 2. Modify post-processing**. Prospect Information： Currently, the inferencer plugin in CNStream provides two network preprocessing methods: Specifies that cpu_preproc preprocesses the input image on the CPU. Applicable to situations where >b cannot complete pre-processing, such as yolov3. If cpu_preproc is NULL, the MLU is used for pre-processing. The offline model needs to have the ability to reduce the mean and multiply the scale in the pre-processing. You can achieve the purpose by configuring the first-level convolution of the mean_value and std parameters. The inferencer plugin performs color space conversion (YUV various formats to RGBA format) and image reduction before performing offline inferencing. a. Configure the pre-processing based on foreground information. If the CPU is used for pre-processing, the corresponding pre-processing function is implemented first. Then modify the cpu_preproc parameter specified when creating the inferencer plugin in the demo, so that it points to the implemented pre-processing function. b. Configure the post-processing. Implement the post-processing: #include class MyPostproc : public Postproc, virtual public edk::ReflexObjectEx { public: void Execute(std::vector> net_outputs, CNFrameInfoPtr data) override { /* net_outputs : the result of the inference net_outputs[i].first : The data pointer of the i-th (starting from 0) output of the offline model. net_outputs[i].second : The length of the output data of the i-th (starting from 0) of the offline model. */ /*Do something and put the detection information into data*/ } DECLARE_REFLEX_OBJECT_EX(SsdPostproc, Postproc)}; // class MyPostproc

. Modify the postproc_name parameter in cnstream/samples/demo/detection_config.json to the post-processing class name (MyPostproc).

Documentation

CNStream Read-the-Docs or Cambricon Forum Docs

Check out the Examples page for tutorials on how to use CNStream. Concepts page for basic definitions

Community forum

Discuss - General community discussion around CNStream
