QNNPACK

QNNPACK (Quantized Neural Networks PACKage) is a mobile-optimized library for low-precision high-performance neural network inference. QNNPACK provides implementation of common neural network operators on quantized 8-bit tensors.

QNNPACK is not intended to be directly used by machine learning researchers; instead it provides low-level performance primitives for high-level deep learning frameworks. As of today, QNNPACK is integrated in PyTorch 1.0 with Caffe2 graph representation.

Operator Coverage

Currently implemented and planned for implementation operators are below:

2D Convolution 2D Deconvolution Channel Shuffle Fully Connected Locally Connected 2D Max Pooling 2D Average Pooling Global Average Pooling Sigmoid Leaky ReLU Clamp (can be used for ReLU, ReLU6 if it is not fused in another operator) SoftArgMax (aka SoftMax) Group Normalization

Building

QNNPACK provides standard CMake-based build scripts.

Native compilation

Users are recommended to use scripts/build-local.sh script to build QNNPACK for the host machine.

Cross-compilation for Android

To cross-compile for Android, set $ANDROID_NDK environment variable (where $ANDROID_NDK is the path to Android NDK directory, e.g. /opt/android-ndk-r15c) and use one of the scripts from the table below:

Notes:

On armeabi-v7a qnnp_initialize will fail with qnnp_status_unsupported_hardware if the mobile CPU does not support ARM NEON. Don't set -DANDROID_ARM_NEON=1 for QNNPACK compilation as it can make qnnp_initialize crash on CPUs without ARM NEON.

Cross-compilation for iOS

To cross-compile for iOS, clone ios-cmake, and set $IOS_CMAKE_TOOLCHAIN_FILE environment variable (where $IOS_CMAKE_TOOLCHAIN_FILE is the path to ios.toolchain.cmake file in ios-cmake), and use one of the scripts from the table below:

End-to-End Benchmarking

Caffe2 backend of PyTorch 1.0 natively integrates QNNPACK, and provides a pre-trained quantized MobileNet v2 model. Below are instructions for benchmarking this model end-to-end with QNNPACK.

Raspberry Pi 2 or 3

# Clone PyTorch 1.0 repogit clone --recursive https://github.com/pytorch/pytorch.gitcd pytorch# Optional: update QNNPACK submodule to latest revisiongit submodule update --remote third_party/QNNPACK# Build Caffe2 (including binaries) for the host system# Use only 1 thread for build to avoid out-of-memory failuresMAX_JOBS=1 scripts/build_local.sh -DBUILD_BINARY=ON -DBUILD_PYTHON=OFF \ -DUSE_OBSERVERS=OFF -DUSE_DISTRIBUTED=OFF# Download model weightswget https://s3.amazonaws.com/download.caffe2.ai/models/mobilenet_v2_1.0_224_quant/init_net.pb# Download model graphwget https://s3.amazonaws.com/download.caffe2.ai/models/mobilenet_v2_1.0_224_quant/predict_net.pb# Run speed benchmark with 50 warm-up iterations and 10 measurement iterationsbuild/bin/speed_benchmark --net predict_net.pb --init_net init_net.pb \ --input data --input_dims 1,3,224,224 --input_type float \ --warmup 50 --iter 10

ARMv7 (32-bit) Android

# Clone PyTorch 1.0 repogit clone --recursive https://github.com/pytorch/pytorch.gitcd pytorch# Optional: update QNNPACK submodule to latest revisiongit submodule update --remote third_party/QNNPACK# Build Caffe2 (including binaries) for Android, and push to devicescripts/build_android.sh -DANDROID_TOOLCHAIN=clang -DBUILD_BINARY=ONadb push build_android/bin/speed_benchmark /data/local/tmp/speed_benchmark# Download model weights and copy them to Android devicewget https://s3.amazonaws.com/download.caffe2.ai/models/mobilenet_v2_1.0_224_quant/init_net.pbadb push init_net.pb /data/local/tmp/init_net.pb# Download model graph and copy it to Android devicewget https://s3.amazonaws.com/download.caffe2.ai/models/mobilenet_v2_1.0_224_quant/predict_net.pbadb push predict_net.pb /data/local/tmp/predict_net.pb# Run speed benchmark with 50 warm-up iterations and 10 measurement iterationsadb shell /data/local/tmp/speed_benchmark \ --net /data/local/tmp/predict_net.pb \ --init_net /data/local/tmp/init_net.pb \ --input data --input_dims 1,3,224,224 --input_type float \ --warmup 50 --iter 10

ARM64 (64-bit) Android

# Clone PyTorch 1.0 repogit clone --recursive https://github.com/pytorch/pytorch.gitcd pytorch# Optional: update QNNPACK submodule to latest revisiongit submodule update --remote third_party/QNNPACK# Build Caffe2 (including binaries) for Android, and push to devicescripts/build_android.sh -DANDROID_ABI=arm64-v8a -DANDROID_TOOLCHAIN=clang -DBUILD_BINARY=ONadb push build_android/bin/speed_benchmark /data/local/tmp/speed_benchmark# Download model weights and copy them to Android devicewget https://s3.amazonaws.com/download.caffe2.ai/models/mobilenet_v2_1.0_224_quant/init_net.pbadb push init_net.pb /data/local/tmp/init_net.pb# Download model graph and copy it to Android devicewget https://s3.amazonaws.com/download.caffe2.ai/models/mobilenet_v2_1.0_224_quant/predict_net.pbadb push predict_net.pb /data/local/tmp/predict_net.pb# Run speed benchmark with 50 warm-up iterations and 10 measurement iterationsadb shell /data/local/tmp/speed_benchmark \ --net /data/local/tmp/predict_net.pb \ --init_net /data/local/tmp/init_net.pb \ --input data --input_dims 1,3,224,224 --input_type float \ --warmup 50 --iter 10

PEP (Performance Evaluation Platform) Method

Facebook AI Performance Evaluation Platform is a framework and backend agnostic benchmarking platform to compare machine learning inferencing runtime metrics on a set of models and a variety of backends.

We use PEP to produce the results we have in our blog

With an ARMv7 device connected:

# Clone PyTorch 1.0 repomkdir ~/Code && cd ~/Codegit clone --recursive https://github.com/pytorch/pytorch.gitcd pytorch# Optional: update QNNPACK submodule to latest revisiongit submodule update --remote third_party/QNNPACK# Clone PEP repocd ~/Codegit clone --recursive https://github.com/facebook/FAI-PEP.git aibenchcd aibench# Run PEP benchmark with cool specifications. Try changing that cmd with more specifications!# First time compile could take 20+ minutes./benchmarking/run_bench.py \ --platform android \ -b ~/Code/aibench/specifications/models/caffe2/mobilenet_v2/mobilenet_v2_quant.json \ --platform android --repo_dir ~/Code/pytorch \ --frameworks_dir ~/Code/aibench/specifications/frameworks --framework caffe2

Acknowledgements

QNNPACK is developed by Marat Dukhan, Yiming Wu, Hao Lu, and Bert Maher. We thank Andrew Tulloch and Yangqing Jia for advice during the development of QNNPACK.

License

QNNPACK is BSD licensed, as found in the LICENSE file.
