SpringCloud Gateway实现API接口加解密

网友投稿 765 2022-09-28

SpringCloud Gateway实现API接口加解密

目录接口范围启用禁用/版本加密算法报文格式网关实现细节代码filter过滤器请求配置和请求方式分发Get请求参数解密包装 ServerHttpRequestDecoratorpost请求参数解密包装 ServerHttpRequestDecoratorGET/POST返回值加密处理CryptoServerHttpResponseDecorator完整CryptoFilter实现

接口范围

所有GET请求白名单除外

body 体是 application_json 和 application_json_utf8 的 POST请求白名单除外

POST url传参也支持白名单除外

启用禁用/版本

后端提供独立接口（或者现有接口）查询是否需要启用加密功能（如果后端启用了，前端请求被拦截修改为为启用，接口也无法访问回报解密错误），此接口明文传输

请求头增加一个加密版本字段，标识当前的加密算法版本：crypto-version: 1.0.0

加密算法

考虑到全局加密，使用AES加密方式性能更高

加密字符串：原始数据 > AES加密后的字节数组 > Base64编码处理

解密字符串：Base64密文 > AES密文 -> 原始字符串

AES加密细节：

aesKey：32/16 位由后端同一生成

iv：aesKey

mode：CBC

padding：pkcs7

js例子

//加密

static encryptAES(data, key) {

const dataBytes = CryptoJS.enc.Utf8.parse(data);

const keyBytes = CryptoJS.enc.Utf8.parse(key);

const encrypted = CryptoJS.AES.encrypt(dataBytes, keyBytes, {

iv: keyBytes,

mode: CryptoJS.mode.CBC,

padding: CryptoJS.pad.Pkcs7

});

return CryptoJS.enc.Base64.stringify(encrypted.ciphertext);

}

报文格式

GET

url：/app/xx/xx?xx=1

加密处理

秘钥：xxxxxxxxxxxxxxxx

加密文本：{"xx":1}

密文：xq4YR89LgUs4V5N5juKgW5hIsiOsCxBOwzX632S8NV4=

加密后的请求

/app/xx/xx?data=xq4YR89LgUs4V5N5juKgW5hIsiOsCxBOwzX632S8NV4=

POST

url：/app/xx/xx/xxx

json body:

{"xxx1":"111","xxx2":"huawei","xxx3":"789","xxx4":101,"xxx5":2}

加密处理

秘钥：xxxxxxxxxxxxxxxx

加密文本：

{"xxx1":"111","xxx2":"huawei","xxx3":"789","xxx4":101,"xxx5":2}

密文：1oUTYvWfyaeTJ5/wJTVBqUv0Dz0IAUQTZtxSKY9WLZZl8pILP2Sozk5yOYg9I1WTvzgbbGRDGcWV1ASpYykyS1Fq5cT8s3aLXQ6NMo0AaMOC9L0aVpR863qWso5O8aG3

加密后的请求*

json body:

{

"data": "1oUTYvWfyaeTJ5/wJTVBqUv0Dz0IAUQTZtxSKY9WLZZl8pILP2Sozk5yOYg9I1WTvzgbbGRDGcWV1ASpYykyS1Fq5cT8s3aLXQ6NMo0AaMOjt4G9dK0WwhMGZofYuBKmdF27R8Qkr3VtZvjadtvBazJurITyE7hFcr43nlHSL5E="

}

POST url传参和GET格式一致

网关实现细节代码

基于GlobalFilter 接口包装请求request和响应response，先列出关键代码，完整代码见文末

filter过滤器请求配置和请求方式分发

@Override

public Mono filter(ServerWebExchange exchange, GatewayFilterChain chain) {

if (!cryptoProperties.isEnabled()) {

return chain.filter(exchange);

}

ServerHttpRequest request = exchange.getRequest();

//校验请求路径跳过加密

String originalRequestUrl = RequestProvider.getOriginalRequestUrl(exchange);

String path = exchange.getRequest().getURI().getPath();

if (isSkip(path) || isSkip(originalRequestUrl)) {

return chain.filter(exchange);

}

HttpHeaders headers = request.getHeaders();

MediaType contentType = headers.getContentType();

//后期算法升级扩展,暂时只判断是否相等

if (!cryptoProperties.getCryptoVersion().equals(headers.getFirst(cryptoProperties.getCryptoVersionHeader()))) {

return Mono.error(new CryptoException("加密版本不支持"));

}

if (request.getMethod() == HttpMethod.GET) {

return this.handleGetReq(exchange, chain);

} else if (request.getMethod() == HttpMethod.POST &&

(contentType == null ||

MediaType.APPLICATION_JSON.equals(contentType) ||

MediaType.APPLICATION_JSON_UTF8.equals(contentType))) {

return this.handlePostReq(exchange, chain);

} else {

return chain.filter(exchange);

}

Get请求参数解密包装 ServerHttpRequestDecorator

//构造查询参数Map

MultiValueMap map = buildMultiValueMap(dataJson);

//新的解密后的uri

ServerHttpRequest newhttp://HttpRequest = this.buildNewServerHttpRequest(request, map);

//新的解密后的uri request

ServerHttpRequestDecorator decorator = new ServerHttpRequestDecorator(newHttpRequest) {

@Override

public MultiValueMap getQueryParams() {

return map;

}

};

post请求参数解密包装 ServerHttpRequestDecorator

//构造一个请求包装

final MultiValueMap finalQueryParamMap = new LinkedMultiValueMap<>(queryParamMap);

ServerHttpRequestDecorator decorator = new ServerHttpRequestDecorator(request) {

@Override

public HttpHeaders getHeaders() {

HttpHeaders httpHeaders = new HttpHeaders();

httpHeaders.putAll(super.getHeaders());

httpHeaders.remove(HttpHeaders.CONTENT_LENGTH);

httpHeaders.set(HttpHeaders.TRANSFER_ENCODING, "chunked");

return httpHeaders;

}

//处理post url传参解密

@Override

public MultiValueMap getQueryParams() {

if (queryParamsDecrypt) {

return finalQueryParamMap;

}

return super.getQueryParams();

}

@Override

public Flux getBody() {

//注意: 这里需要buffer一下,拿到完整报文后再map解密

return super.getBody().buffer().map(buffer -> {

DataBuffer joinDataBuffer = dataBufferFactory.join(buffer);

byte[] content = new byte[joinDataBuffer.readableByteCount()];

joinDataBuffer.read(content);

DataBufferUtils.release(joinDataBuffer);

String decryptData = new String(content, StandardCharsets.UTF_8);

log.info("post decryptData: {}", decryptData);

if (!queryParamsDecrypt && StringUtils.isEmpty(decryptData)) {

throw new CryptoException("参数格式错误");

} else {

JSONObject dataJsonObj = JSON.parseObject(decryptData);

if (!queryParamsDecrypt && !dataJsonObj.containsKey(cryptoProperties.getParamName())) {

throw new CryptoException("参数格式错误");

}

byte[] bytes = AesUtil.decryptFormBase64(dataJsonObj.getString(cryptoProperties.getParamName()), cryptoProperties.getAesKey());

return dataBufferFactory.wrap(Objects.requireNonNull(bytes));

}

});

GET/POST返回值加密处理CryptoServerHttpResponseDecorator

class CryptoServerHttpResponseDecorator extends ServerHttpResponseDecorator {

final DataBufferFactory bufferFactory;

boolean isPass = false;

public CryptoServerHttpResponseDecorator(ServerHttpResponse delegate) {

super(delegate);

bufferFactory = delegate.bufferFactory();

}

@Override

public HttpHeaders getHeaders() {

HttpHeaders headers = super.getHeaders();

//同一个请求此处有可能调用多次,先重置为false

isPass = false;

if (headers.getContentType() != null &&

!MediaType.APPLICATION_JSON.equals(headers.getContentType()) &&

!MediaType.APPLICATION_JSON_UTF8.equals(headers.getContentType())) {

//相应体ContentType只处理json

isPass = true;

} else if (!headers.containsKey(cryptoProperties.getCryptoVersionHeader())) {

//添加version响应头

headers.add(cryptoProperties.getCryptoVersionHeader(), cryptoProperties.getCryptoVersion());

}

return headers;

}

//调用 writeWith 和 writeAndFlushWith 判断: NettyWriteResponseFilter

// application/json;charset=UTF-8 走这里

@Override

public Mono writeWith(Publisher extends DataBuffer> body) {

if (body instanceof Flux && !isPass) {

Flux extends DataBuffer> fluxBody = (Flux extends DataBuffer>) body;

return super.writeWith(fluxBody.buffer().map(dataBuffer -> {

DataBuffer joinDataBuffer = bufferFactory.join(dataBuffer);

byte[] content = new byte[joinDataBuffer.readableByteCount()];

joinDataBuffer.read(content);

DataBufferUtils.release(joinDataBuffer);

Map data = new HashMap<>(1);

data.put(cryptoProperties.getParamName(), AesUtil.encryptToBase64(content, cryptoProperties.getAesKey()));

return bufferFactory.wrap(JSON.toJSONString(data).getBytes(StandardCharsets.UTF_8));

}));

}

return super.writeWith(body);

}

// StreamingMediaType类型:application/stream 和 application/stream+json 走这里

@Override

public Mono writeAndFlushWith(Publisher extends Publisher extends DataBuffer>> body) {

return super.writeAndFlushWith(body);

}

完整CryptoFilter实现

package org.xx.xx.gateway.filter;

import com.alibaba.fastjson.JSON;

import com.alibaba.fastjson.JSONObject;

import com.google.common.collect.Lists;

import io-ty.buffer.ByteBufAllocator;

import lombok.RequiredArgsConstructor;

import lombok.SneakyThrows;

import lombok.extern.slf4j.Slf4j;

import org.reactivestreams.Publisher;

import org.xx.xx.gateway.props.CryptoProperties;

import org.xx.xx.gateway.provider.RequestProvider;

import org.xx.xx.gateway.provider.ResponseProvider;

import org.xx.xx.gateway.util.AesUtil;

import org.xx.xx.gateway.util.StringPool;

import org.springframework.boot.autoconfigure.condition.ConditionalOnProperty;

import org.springframework.cloud.gateway.filter.GatewayFilterChain;

import org.springframework.cloud.gateway.filter.GlobalFilter;

import org.springframework.context.annotation.Configuration;

import org.springframework.core.Ordered;

import org.springframework.core.io.buffer.DataBuffer;

import org.springframework.core.io.buffer.DataBufferFactory;

import org.springframework.core.io.buffer.DataBufferUtils;

import org.springframework.core.io.buffer.NettyDataBufferFactory;

import org.springframework.http.HttpHeaders;

import org.springframework.http.HttpMethod;

import org.springframework.http.HttpStatus;

import org.springframework.http.MediaType;

import org.springframework.http.server.reactive.ServerHttpRequest;

import org.springframework.http.server.reactive.ServerHttpRequestDecorator;

import org.springframework.http.server.reactive.ServerHttpResponse;

import org.springframework.http.server.reactive.ServerHttpResponseDecorator;

import org.springframework.util.AntPathMatcher;

import org.springframework.util.LinkedMultiValueMap;

import org.springframework.util.MultiValueMap;

import org.springframework.util.StringUtils;

import org.springframework.web.server.ServerWebExchange;

import reactor.core.publisher.Flux;

import reactor.core.publisher.Mono;

import java-.URI;

import java-.URISyntaxException;

import java.nio.charset.StandardCharsets;

import java.util.HashMap;

import java.util.Map;

import java.util.Objects;

/**

* CryptoFilter

* @author lizheng

* @version 1.0

* @date 2022/3/11 上午10:57

@Slf4j

@RequiredArgsConstructor

@Configuration

@ConditionalOnProperty(value = "gateway.crypto.enabled", havingValue = "true", matchIfMissing = true)

public class CryptoFilter implements GlobalFilter, Ordered {

private final AntPathMatcher antPathMatcher = new AntPathMatcher();

private final DataBufferFactory dataBufferFactory = new NettyDataBufferFactory(ByteBufAllocator.DEFAULT);

private final CryptoProperties cryptoProperties;

@Override

public Mono filter(ServerWebExchange exchange, GatewayFilterChain chain) {

if (!cryptoProperties.isEnabled()) {

return chain.filter(exchange);

}

ServerHttpRequest request = exchange.getRequest();

//校验请求路径跳过加密

String originalRequestUrl = RequestProvider.getOriginalRequestUrl(exchange);

String path = exchange.getRequest().getURI().getPath();

if (isSkip(path) || isSkip(originalRequestUrl)) {

return chain.filter(exchange);

}

HttpHeaders headers = request.getHeaders();

MediaType contentType = headers.getContentType();

//后期算法升级扩展,暂时只判断是否相等

if (!cryptoProperties.getCryptoVersion().equals(headers.getFirst(cryptoProperties.getCryptoVersionHeader()))) {

return Mono.error(new CryptoException("加密版本不支持"));

}

if (request.getMethod() == HttpMethod.GET) {

return this.handleGetReq(exchange, chain);

} else if (request.getMethod() == HttpMethod.POST &&

(contentType == null ||

MediaType.APPLICATION_JSON.equals(contentType) ||

MediaType.APPLICATION_JSON_UTF8.equals(contentType))) {

return this.handlePostReq(exchange, chain);

} else {

return chain.filter(exchange);

}

class CryptoServerHttpResponseDecorator extends ServerHttpResponseDecorator {

final DataBufferFactory bufferFactory;

boolean isPass = false;

public CryptoServerHttpResponseDecorator(ServerHttpResponse delegate) {

super(delegate);

bufferFactory = delegate.bufferFactory();

}

@Override

public HttpHeaders getHeaders() {

HttpHeaders headers = super.getHeaders();

//同一个请求此处有可能调用多次,先重置为false

isPass = false;

if (headers.getContentType() != null &&

!MediaType.APPLICATION_JSON.equals(headers.getContentType()) &&

!MediaType.APPLICATION_JSON_UTF8.equals(headers.getContentType())) {vdLtenuaF

//相应体ContentType只处理json

isPass = true;

} else if (!headers.containsKey(cryptoProperties.getCryptoVersionHeader())) {

//添加version响应头

headers.add(cryptoProperties.getCryptoVersionHeader(), cryptoProperties.getCryptoVersion());

}

return headers;

}

//调用 writeWith 和 writeAndFlushWith 判断: NettyWriteResponseFilter

// application/json;charset=UTF-8 走这里

@Override

public Mono writeWith(Publisher extends DataBuffer> body) {

if (body instanceof Flux && !isPass) {

Flux extends DataBuffer> fluxBody = (Flux extends DataBuffer>) body;

return super.writeWith(fluxBody.buffer().map(dataBuffer -> {

DataBuffer joinDataBuffer = bufferFactory.join(dataBuffer);

byte[] content = new byte[joinDataBuffer.readableByteCount()];

joinDataBuffer.read(content);

DataBufferUtils.release(joinDataBuffer);

Map data = new HashMap<>(1);

data.put(cryptoProperties.getParamName(), AesUtil.encryptToBase64(content, cryptoProperties.getAesKey()));

return bufferFactory.wrap(JSON.toJSONString(data).getBytes(StandardCharsets.UTF_8));

}));

}

return super.writeWith(body);

}

// StreamingMediaType类型:application/stream 和 application/stream+json 走这里

@Override

public Mono writeAndFlushWith(Publisher extends Publisher extends DataBuffer>> body) {

return super.writeAndFlushWith(body);

}

@SneakyThrows

private Mono handlePostReq(ServerWebExchange exchange, GatewayFilterChain chain) {

ServerHttpRequest request = exchange.getRequest();

String paramData = request.getQueryParams().getFirst(cryptoProperties.getParamName());

MultiValueMap queryParamMap = new LinkedMultiValueMap<>();

final boolean queryParamsDecrypt = !StringUtils.isEmpty(paramData);

if (queryParamsDecrypt) {

String dataJson;

try {

//AES解密

dataJson = AesUtil.decryptFormBase64ToString(paramData, cryptoProperties.getAesKey());

} catch (Exception e) {

log.error("请求参数解密异常: ", e);

return cryptoError(exchange.getResponse(), "请求参数解密异常");

}

//构造查询参数Map

queryParamMap = buildMultiValueMap(dataJson);

//新的解密后的uri request

request = this.buildNewServerHttpRequest(request, queryParamMap);

}

//构造一个请求包装

final MultiValueMap finalQueryParamMap = new LinkedMultiValueMap<>(queryParamMap);

ServerHttpRequestDecorator decorator = new ServerHttpRequestDecorator(request) {

@Override

public HttpHeaders getHeaders() {

HttpHeaders httpHeaders = new HttpHeaders();

httpHeaders.putAll(super.getHeaders());

httpHeaders.remove(HttpHeaders.CONTENT_LENGTH);

httpHeaders.set(HttpHeaders.TRANSFER_ENCODING, "chunked");

return httpHeaders;

}

@Override

public MultiValueMap getQueryParams() {

if (queryParamsDecrypt) {

return finalQueryParamMap;

}

return super.getQueryParams();

}

@Override

public Flux getBody() {

//注意: 这里需要buffer,拿到完整报文后再map解密

return super.getBody().buffer().map(buffer -> {

DataBuffer joinDataBuffer = dataBufferFactory.join(buffer);

byte[] content = new byte[joinDataBuffer.readableByteCount()];

joinDataBuffer.read(content);

DataBufferUtils.release(joinDataBuffer);

String decryptData = new String(content, StandardCharsets.UTF_8);

log.info("post decryptData: {}", decryptData);

if (!queryParamsDecrypt && StringUtils.isEmpty(decryptData)) {

throw new CryptoException("参数格式错误");

} else {

JSONObject dataJsonObj = JSON.parseObject(decryptData);

if (!queryParamsDecrypt && !dataJsonObj.containsKey(cryptoProperties.getParamName())) {

throw new CryptoException("参数格式错误");

}

byte[] bytes = AesUtil.decryptFormBase64(dataJsonObj.getString(cryptoProperties.getParamName()), cryptoProperties.getAesKey());

return dataBufferFactory.wrap(Objects.requireNonNull(bytes));

}

});

}

};

return chain.filter(exchange.mutate()

.request(decorator)

.response(new CryptoServerHttpResponseDecorator(exchange.getResponse()))

.build());

}

@SneakyThrows

private Mono handleGetReq(ServerWebExchange exchange, GatewayFilterChain chain) {

ServerHttpRequest request = exchange.getRequest();

if (request.getQueryParams().isEmpty()) {

// get无参数不走参数解密

return chain.filter(exchange.mutate()

.request(request)

.response(new CryptoServerHttpResponseDecorator(exchange.getResponse()))

.build());

}

String paramData = request.getQueryParams().getFirst(cryptoProperties.getParamName());

if (StringUtils.isEmpty(paramData)) {

//有参数但是密文字段不存在

throw new CryptoException("参数格式错误");

}

String dataJson;

try {

//AES解密

dataJson = AesUtil.decryptFormBase64ToString(paramData, cryptoProperties.getAesKey());

} catch (Exception e) {

log.error("请求参数解密异常: ", e);

return cryptoError(exchange.getResponse(), "请求参数解密异常");

}

//构造查询参数Map

MultiValueMap map = buildMultiValueMap(dataJson);

//新的解密后的uri

ServerHttpRequest newHttpRequest = this.buildNewServerHttpRequest(request, map);

//新的解密后的uri request

ServerHttpRequestDecorator decorator = new ServerHttpRequestDecorator(newHttpRequest) {

@Override

public MultiValueMap getQueryParams() {

return map;

}

};

return chain.filter(exchange.mutate()

.request(decorator)

.response(new CryptoServerHttpResponseDecorator(exchange.getResponse()))

.build());

}

private MultiValueMap buildMultiValueMap(String dataJson) {

vdLtenuaF JSONObject jsonObject = JSON.parseObject(dataJson);

MultiValueMap map = new LinkedMultiValueMap<>(jsonObject.size());

for (String key : jsonObject.keySet()) {

map.put(key, Lists.newArrayList(jsonObject.getString(key)));

}

return map;

}

private ServerHttpRequest buildNewServerHttpRequest(ServerHttpRequest request, MultiValueMap params) throws URISyntaxException {

StringBuilder queryBuilder = new StringBuilder();

for (String key : params.keySet()) {

queryBuilder.append(key);

queryBuilder.append(StringPool.EQUALS);

queryBuilder.append(params.getFirst(key));

queryBuilder.append(StringPool.AMPERSAND);

}

queryBuilder.deleteCharAt(queryBuilder.length() - 1);

//经过测试只覆盖 ServerHttpRequest的getQueryParams路由分发之后,无法携带过去新的参数,所以这里需要构造一个新的解密后的uri

URI uri = request.getURI();

URI newUri = new URI(uri.getScheme(),

uri.getUserInfo(),

uri.getHost(),

uri.getPort(),

uri.getPath(),

queryBuilder.toString(),

uri.getFragment());

//构造一个新的ServerHttpRequest

return request.mutate().uri(newUri).build();

}

private boolean isSkip(String path) {

for (String pattern : cryptoProperties.getSkipPathPattern()) {

if (antPathMatcher.match(pattern, path)) {

return true;

}

return false;

}

private Mono cryptoError(ServerHttpResponse resp, String msg) {

resp.setStatusCode(HttpStatus.UNAUTHORIZED);

resp.getHeaders().add("Content-Type", "application/json;charset=UTF-8");

String result = JSON.toJSONString(ResponseProvider.unAuth(msg));

DataBuffer buffer = resp.bufferFactory().wrap(result.getBytes(StandardCharsets.UTF_8));

return resp.writeWith(Flux.just(buffer));

}

@Override

public int getOrder() {

return -200;

}

以上就是SpringCloud Gateway实现API接口加解密的详细内容，更多关于SpringCloud Gateway接口加解密的资料请关注我们其它相关文章！

随着系统集成技术的发展，如何利用小程序容器技术提升企业的数字化转型效率是现代企业面临的重要挑战。企业应关注如何实现跨平台兼容、数据安全管理以及全生命周期管理，确保运营合规与灵活应变，以适应不断变化的市场需求和技术环境。

765 2022-09-28

SpringCloud Gateway实现API接口加解密

如何利用小游戏开发框架提升企业小程序的用户体验与运营效率

政务服务平台开发需要注意如何提升小程序跨平台兼容性与用户体验

最近发表

更多内容

小程序SDK

Finclip技术文档

小程序开发

小程序容器

小程序框架

Finclip小程序平台

Finclip用户投稿

车联网

推荐文章

小程序SDK是什么意思？小程序sdk和插件有什么区别？

小程序支付功能怎么实现？

企业app开发流程是什么？

app运营模式有哪些？

小程序多端引流怎么做？

小程序生态分析的机会和威胁

Flutter入门这一篇效率文章就够了

原生与跨平台解决方案分析,跨平台软件开发技术方案

热更新技术：让软件更新变得更加轻松快速

解决方案

银行解决方案

证券解决方案

互联网解决方案

政企OA解决方案

科技解决方案

loT解决方案

信任解决方案

热评文章

AppCan:基于混合模式的移动应用开发,移动混合模

Hybrid App混合模式开发的了解

小程序容器技术助力券商数字营销突围，小程序容器化的意

用mpvue开发微信小程序基础知识（vue.js开发

小程序多端框架全面测评对比，强烈推荐！

券商app架构 - 解析券商应用程序的构建与设计
